Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1023850 | ASM-FRAME TUBE FRONT RMK CF [INCL. FOIL] | 1 |
| 5 | 7547332 | NYLOC OLIVE NUT, 8 MM X 1.25 MM | 5 |
| 2 | 7518906 | CL8.8 OLV-D | 2 |
| 1 | 1024086-067 | CROSS BRACE WELD, MEDIUM GLOSS | 1 |
| 1 | 5814124 | FOIL-100MM X 200MM | 1 |
| 4 | 7520721 | SCR-HXFL-M6X1.0X55 10.9 ZODP30 | 4 |
| 2 | 5633083 | CAST TUBE SHIM, 31.76 DIA | 2 |
| 2 | 5632923 | TUBE CAST SPACER | 2 |
| 1 | 1023201 | FRAME ASSEMBLY, TUBULAR, REAR, | 1 |
| 2 | 1019337 | STUD PLATE ASSEMBLY | 2 |
| 1 | 7081808 | CABLE TIE STRAP WITH EDGE CLIP | 1 |
| 7 | 7661637 | RIVET | 7 |
| 1 | 5262012 | BRKT-SUPT TOE STOP | 1 |
| 4 | 7547453 | HEX FLANGE NUT, 6 MM X 1.0 MM | 4 |
| 1 | 1023315-309 | ASM-CHASSIS 850 163 QD NAT [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-309 | ASM-CHASSIS 850 163 CC BSC NAT [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1 | 1023313-309 | ASM-TUNNEL 850 163 NAT [SNOW CHECK SELECT] | 1 |
| 1 | 1023315-067 | CHASSIS ASSEMBLY, MEDIUM GLOSS [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-067 | CHASSIS ASSEMBLY, MEDIUM GLOSS [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1 | 1023313-067 | TUNNEL ASSEMBLY, MEDIUM GLOSS B [SNOW CHECK SELECT] | 1 |
| 1 | 1023315-293 | CHASSIS ASSEMBLY, INDY RED [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-293 | ASM-CHASSIS 850 163 CC IRED [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1 | 1023313-293 | ASM-TUNNEL 850 163 IRED [SNOW CHECK SELECT] | 1 |
| 1 | 1023315-630 | ASM-CHASSIS 850 163 QD LMSQU [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-630 | CHASSIS ASM 850 163 CC LIME SQU [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1023313-630 | ASM-TUNNEL 850 163 LMSQU [SNOW CHECK SELECT] | ||
| 1 | 1023315-647 | ASM-CHASSIS 850 163 QD ORGBST [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-647 | ASM-CHASSIS 850 163 CC ORGBST [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1 | 1023313-647 | TUNNEL ASSEMBLY, ORANGE BURST [SNOW CHECK SELECT] | 1 |
| 1 | 1023315-737 | CHASSIS ASSEMBLY, 850, INDIAN S [SC SELECT][INCL. BULKHEAD AND QUICK DRIVE] | 1 |
| 1 | 1023980-737 | ASM-CHASSIS 850 163 CC ISBLU [SC SELECT 3" TRACK MODEL][INCL. BULKHEAD AND CHAINCASE] | 1 |
| 1 | 1023313-737 | TUNNEL ASSEMBLY, INDIAN SKY BLU [SNOW CHECK SELECT] | 1 |
| 1 | 7080539 | CLAMP,NYLON,CABLE | 1 |
| 1 | 7662251 | RIVET-4.8MM DIA-1.5-6.0GRIP(4) | 1 |
| 3 | 5814353 | PAD, 40 X 63.5 | 3 |
| 1 | 5258618 | AIRBOX SUPPORT BRACKET | 1 |
| 4 | 7519070 | SCR-TXTH-M8X1.25X25 8.8 ZODP30 | 4 |
| 4 | 7519338 | SCR-RHCAR-M6X1.0X20 8.8 ZPC | 4 |
| 1 | 1023231 | ASM-REGULATOR MOUNT RMK | 1 |
| 1 | 5814828 | PAD-4411G,40MIL,51X22 | 1 |
| 1 | 5454789 | MOUNT-LOAD CENTER | 1 |
| 1 | 5265340 | BRKT-LOAD CENTER | 1 |
| 6 | 7661973 | RIVET, 4.8 MM | 6 |
| 2 | 7081496 | ROUTING CLIP | 2 |
