Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 291004646 | Deep Black, Mid Deck | ||
| 10 | 291003880 | Oval Washer | 10 |
| 10 | 250000827 | Torx Screw Truss Cone HD.M6X50 | 10 |
| 10 | 234062600 | Flat Washer M6, Stainless | 10 |
| 10 | 232561200 | Brass Elastic Stop Nut M6 | 10 |
| 1 | 291005057 | Console Front | 1 |
| 2 | 250000827 | Torx Screw Truss Cone HD.M6X50 | 2 |
| 2 | 250200150 | Flat Washer M6, Stainless | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 232561200 | Brass Elastic Stop Nut M6 | 2 |
| 2 | 291003880 | Oval Washer | 2 |
| 1 | 291005190 | Dazzling Blue, Front Deck Model Manta Green | 1 |
| 1 | 291004727 | Deep Black, Front Deck Model Mango Orange | 1 |
| 12 | 291003880 | Oval Washer | 12 |
| 12 | 250000828 | Screw Torx M6.81 X 30 | 12 |
| 5 | 291003793 | Insert | 5 |
| 1 | 293250341 | Seal Joint | 1 |
| 5 | 291003880 | Oval Washer | 5 |
| 5 | 250000828 | Screw Torx M6.81 X 30 | 5 |
| 1 | 291005191 | Dazzling Blue, Rear Deck Model Manta Green | 1 |
| 1 | 291004730 | Deep Black, Rear Deck Model Mango Orange | 1 |
| 16 | 291003880 | Oval Washer | 16 |
| 16 | 250000828 | Screw Torx M6.81 X 30 | 16 |
| 4 | 291003793 | Insert | 4 |
| 1 | 293250340 | Seal Joint | 1 |
| 6 | 291003880 | Oval Washer | 6 |
| 6 | 250000828 | Screw Torx M6.81 X 30 | 6 |
| 1 | 291003390 | Deep Black, Rear Access Cover | 1 |
| 1 | 291004155 | Deep Black, Front Access Cover Includes 200 to 200d | 1 |
| 1 | 293300121 | O-Ring | 1 |
| 1 | 292000933 | U-Clamp | 1 |
| 2 | 293050001 | Flat Washer M8.5 x 18 | 2 |
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 2 | 232581200 | Hex. Elastic Nut M8 Brass | 2 |
| 1 | 291003883 | Deep Black, LH Rear Panel Trim | 1 |
| 1 | 250000828 | Screw Torx M6.81 X 30 | 1 |
| 1 | 291003793 | Insert | 1 |
| 1 | 291003884 | Deep Black, RH Rear Panel Trim | 1 |
| 1 | 291003378 | Deep Black, Glove Box Cover | 1 |
| 1 | 291004732 | Manta Green, RH Knee Pads Model Manta Green | 1 |
| 1 | 291005094 | RH Molded Knee Pad Model Mango Orange | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 705000321 | Oval Washer | 1 |
| 1 | 291004736 | Manta Green, LH Knee Pads Model Manta Green | 1 |
| 1 | 291005093 | LH Molded Knee Pad Model Mango Orange | 1 |
| 1 | 291004524 | Bright White, LH Panel Trim | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 1 | 211000023 | Hex. Screw 10-14 X 7/8” | 1 |
| 1 | 291004525 | Bright White, RH Panel Trim | 1 |
| 1 | 291004567 | Front Bumper | 1 |
| 1 | 291004568 | Black, LH Rear Bumper | 1 |
| 4 | 250000828 | Screw Torx M6.81 X 30 | 4 |
| 1 | 291004569 | Black, RH Rear Bumper | 1 |
| 1 | 295100864 | Storage Bin Kit Includes 1600 to 1600a | 1 |
| 1 | 295100865 | Black, Front Deflector Kit | 1 |
| 1 | 269800472 | LH Retaining Strap | 1 |
| 1 | 269800498 | RH Retaining Strap | 1 |
| 2 | 250000828 | Screw Torx M6.81 X 30 | 2 |
| 2 | 293830005 | Rubber Bumper | 2 |
| 1 | 269800541 | LH Hook | 1 |
| 1 | 269800542 | RH Hook | 1 |
| 6 | 269800662 | Rubber Bumper | 6 |
| 1 | 291004575 | Black, Inferior Cover | 1 |
| 2 | 211000023 | Hex. Screw 10-14 X 7/8” | 2 |
| 1 | 291004981 | Manta Green, Frontal Trim Model Manta Green | 1 |
| 1 | 291004741 | Orange Mango, Frontal Trim Model Mango Orange | 1 |
| 1 | 250000829 | Torx-Truss M/S Stlss M6 X 20 | 1 |
| 1 | 269502408 | Housing Nut M6 Includes 2285 to 2285a | 1 |
| 1 | 232561200 | Brass Elastic Stop Nut M6 | 1 |
| 1 | 291003702 | Cap | 1 |
| 1 | 291003440 | Rear Support | 1 |
| 2 | 291003793 | Insert | 2 |
| 1 | 291003694 | Rear Support Mount | 1 |
