Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 278002522 | WIRING HARNESS MAIN | |
| 101 | 278001392 | Open Barrel Terminal | 1 |
| 112 | 278000632 | Female Terminal | 1 |
| 113 | 278001661 | FEMALE TERMINAL | |
| 121 | 409207400 | Female Housing, 3 Circuits | 1 |
| 122 | 278000739 | Male Connector, 4 Circuits | 1 |
| 133 | 409207200 | Female Lock | 1 |
| 134 | 278000738 | Male Lock, 4 Circuits | 1 |
| 135 | 278000737 | MALE LOCK, 6 CIRCUITS | 1 |
| 137 | 409015700 | Female Lock, 12 Circuits | 1 |
| 138 | 293000052 | Sealing Cap | 1 |
| 196 | 293750002 | Tie Wrap 142 mm | 1 |
| 242 | 278000218 | Wire Seal | 1 |
| 243 | 710000048 | Wire Seal | 1 |
| 244 | 278000216 | Wire Seal | 1 |
| 420 | 414115200 | Tie-Rap 180 mm | 1 |
| 525 | 710000482 | SHRINK TUBING | |
| 659 | 278001065 | Wire Seal | 1 |
| 666 | 710000742 | Little Fuse, 5 Amperes | 1 |
| 668 | 710000744 | Little Fuse, 10 Amperes | 1 |
| 669 | 710000745 | Little Fuse, 15 Ampere | 1 |
| 671 | 710000747 | Little Fuse, 30 Amperes | 1 |
| 690 | 710000890 | Female Terminal | 1 |
| 732 | 710000877 | Female Terminal | 1 |
| 734 | 710000879 | Female Housing, 3 Circuits | 1 |
| 735 | 710000880 | Housing, 3 Circuits | 1 |
| 736 | 710000881 | Seal | 1 |
| 737 | 710000882 | Cap | 1 |
| 751 | 710000918 | Female Terminal | 1 |
| 757 | 278001665 | Female Terminal | 1 |
| 767 | 278002165 | Bus Bar | 1 |
| 768 | 278002165 | Bus Bar | 1 |
| 770 | 710001008 | Little Fuse, 3 AMP | 1 |
| 771 | 278002168 | Relay, 30 AMP Obsolete. Sea Doo order 278002822 | |
| 775 | 293730040 | Mount Dart | 1 |
| 778 | 278002165 | Bus Bar | 1 |
| 798 | 278002185 | Male Housing, 4 Circuits | 1 |
| 799 | 278002186 | Wire Seal | 1 |
| 800 | 278002187 | Female Terminal | 1 |
| 827 | 710001119 | Female Terminal | 1 |
| 848 | 710001158 | PLUG | 1 |
| 849 | 710001159 | Wire Seal | 1 |
| 850 | 710001160 | Female Terminal | 1 |
| 976 | 710001540 | CONNECTOR_MALE 6 CAVITIES | 1 |
| 995 | 278002165 | Bus Bar | 1 |
| 1006 | 710001588 | Female Terminal Housing, 48 Circuits | 1 |
| 1007 | 710001589 | Female Terminal | 1 |
| 1008 | 710001590 | Female Terminal | 1 |
| 1009 | 710001591 | Cover, 48 positions | 1 |
| 1010 | 710001592 | Plug | 1 |
| 1011 | 710001593 | Plug | 1 |
| 1012 | 278002374 | FEMALE TERMINAL HOUSING, 2 CIRCUITS | 1 |
| 1013 | 278002375 | CONNECTOR_FEMALE 3 CAVITIES | 1 |
| 1015 | 278002377 | Female Terminal Housing, 12 Circuits | 1 |
| 1026 | 278002388 | FEMALE TERMINAL HOUSING, 3 CIRCUITS | 1 |
| 1032 | 710001727 | Female Terminal | 1 |
| 1135 | 278002451 | HOUSING | 1 |
| 1137 | 278002453 | Female Terminal | 1 |
| 1139 | 278002455 | Female Terminal | 1 |
| 1143 | 278002459 | LOCK | |
| 1188 | 278002528 | Fuse Box Ass'y | 1 |
| 1189 | 278002529 | Fuse Cover | 1 |
| 1190 | 278002530 | SEAL | |
| 1204 | 278002578 | Female Terminal | 1 |
| 1212 | 278002596 | Junction Bar (4 Pins) | 1 |
| 1230 | 278002642 | Female Terminal | 1 |
| 2051 | 278002533 | Battery Harness | 1 |
| 2053 | 219903391 | FUSE DECAL (ENGLISH) | 1 |
