Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 517305744 | Black, Front Hood Deep Black | 1 |
| 1 | 517306237 | Bright White, Front Hood Bright White | 1 |
| 1 | 517306635 | Can-Am Red, Front Hood Can-am Red | 1 |
| 1 | 517306794 | Gulfstream Blue, Front Hood Gulfstream Blue | 1 |
| 4 | 250000528 | Torx Screw M5 X 20 | 4 |
| 4 | 250000958 | Panel Nut M5 X 0.8 | 4 |
| 2 | 233151414 | Hex. Flange Nut M5 | 2 |
| 2 | 250200040 | Flat Washer | 2 |
| 2 | 250000587 | Torx Screw M5 X 26 | 2 |
| 2 | 250200166 | Washer | 2 |
| 1 | 517305763 | RH Front Hood Foam | 1 |
| 1 | 517305764 | LH Front Hood Foam | 1 |
| 1 | 517306636 | Rh Hood Can-am Red | 1 |
| 1 | 517306722 | Black, RH Hood Deep Black | 1 |
| 1 | 517306737 | Bright White, RH Hood Bright White | 1 |
| 1 | 517306795 | Gulfstream Blue, RH Hood Gulfstream Blue | 1 |
| 3 | 250000725 | Screw M4 X 16 | 3 |
| 1 | 517306001 | RH Hood Foam | 1 |
| 1 | 517306637 | Can-Am Red, LH Hood Can-am Red | 1 |
| 1 | 517306721 | Black, LH Hood Deep Black | 1 |
| 1 | 517306727 | Bright White, LH Hood Bright White | 1 |
| 1 | 517306796 | Gulfstream Blue, LH Hood Gulfstream Blue | 1 |
| 1 | 517306002 | LH Hood Foam | 1 |
| 1 | 517306898 | Rear Console | 1 |
| 2 | 250000958 | Panel Nut M5 X 0.8 | 2 |
| 1 | 517306602 | Console Nut | 1 |
| 1 | 706002839 | O-Ring | 1 |
| 1 | 517306580 | LH Front Console | 1 |
| 1 | 572051500 | Cap | 1 |
| 1 | 517306117 | Indicator Support Except Package STD | 1 |
| 1 | 517306319 | Indicator Support Package STD | 1 |
| 1 | 860201448 | Black, Low Windshield Kit Package X | 1 |
| 1 | 517306423 | Windshield 360 Package X | 1 |
| 1 | 517305749 | Deep Black, Windshield Support Package X | 1 |
| 6 | 732610072 | Push Nut Package X | 6 |
| 4 | 250200024 | Rubber Washer 5 mm Package X | 4 |
| 2 | 219704372 | Was 293250087 Gasket Package X | 2 |
| 1 | 860201258 | Medium Windshield Kit Package STD | 1 |
| 1 | 517306183 | Deep Black, Windshield Support Package STD | 1 |
| 8 | 732610072 | Push Nut Package STD | 8 |
| 1 | 517306063 | Deflector RH, Black 63% Light Transm. Package STD | 1 |
| 1 | 517306064 | Deflector LH, Black 63% Light Transm. Package STD | 1 |
| 6 | 250000889 | Screw M4 X 16 Package STD | 6 |
| 6 | 517306524 | Rubber Washer 4 MM Package STD | 6 |
| 1 | 517306697 | Wind Deflector Package XRS - Can-Am Red | 1 |
| 1 | 517305875 | Deep Black, Wind Deflector Package XRS - Deep Black | 1 |
| 2 | 517303756 | Grommet | 2 |
| 1 | 517305752 | Headlamp | 1 |
| 1 | 415130081 | Bulb | 1 |
| 1 | 517305776 | RH Deflector Black 63% Light Transm. Package X | 1 |
| 1 | 517306049 | RH Hood Plate Package XRS | 1 |
| 2 | 517302841 | Grommet Except Package XRS | 2 |
| 1 | 517305777 | Deflector LH, Black 63% Light Transm. Package X | 1 |
| 1 | 517306050 | LH Hood Plate Package XRS | 1 |
| 1 | 517305871 | Deep Black, Cover Ass'y Includes 3200 to 3200a | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 517306058 | Trunk Ass'y Includes 3400 to 3400a | 1 |
| 2 | 517305157 | Seal Joint | 2 |
| 1 | 517305746 | Deep Black, Headlamp Fairing | 1 |
| 2 | 250000725 | Screw M4 X 16 | 2 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
