Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94510-19C00 | BRACE, COWLING | ||
| 1 | 01517-08205 | BOLT | 1 |
| 2 | 01517-06125 | BOLT | 2 |
| 2 | 02142-06127 | SCREW | 2 |
| 94520-19C00 | PLATE, METER | ||
| 4 | 02142-06125 | SCREW | 4 |
| 94420-19C00 | COVER, METER (BLACK) Includes Item(s) 8 | ||
| 2 | 94635-19C10 | MOLDING | 2 |
| 4 | 03541-05085 | SCREW | 4 |
| 1 | 94527-19C00 | MOLDING, METER | 1 |
| 94426-19C00 | CUSHION, COVER | ||
| 94610-19C10 | WINDOW | ||
| 1 | 94631-19C00 | MOLDING | 1 |
| 94637-19C00 | CAP | ||
| 4 | 09139-05022 | SCREW | 4 |
| 4 | 09161-05010 | WASHER (5.2X11.0X1.0) | 4 |
| 94460-19C00 | PLATE, CENTER | ||
| 2 | 09136-06081 | SCREW | 2 |
| 2 | 09180-06167 | SPACER | 2 |
| 2 | 09320-10015 | CUSHION (10X20X10) | 2 |
| 1 | 94638-19C00 | CUSHION, SCREEN | 1 |
| 94421-19C00-24V | PANEL, CENTER (BLUE) CLEAR COATING | ||
| 94421-19C01-24V | PANEL, CENTER (BLUE) | ||
| 94421-19C00-28V | PANEL, CENTER (RED) CLEAR COATING | ||
| 94421-19C01-28V | PANEL, CENTER (RED) | ||
| 2 | 02142-05127 | SCREW | 2 |
| 94401-19C40-24V | COVER ASSY, COWLING,RH (BLUE) CLEAR COATING | ||
| 94401-19C41-24V | COVER ASSY, COWLING,RH (BLUE) | ||
| 94401-19C40-28V | COVER ASSY, COWLING,RH (RED) CLEAR COATING | ||
| 94401-19C41-28V | COVER ASSY, COWLING,RH (RED) Includes Item(s) 25 - 32 | ||
| 68180-19C10-71P | TAPE SET, RH FOR 24V | ||
| 68180-19C10-70G | TAPE SET, RH FOR 28V | ||
| 68181-19C00-3AT | EMBLEM, "KATANA" FOR 24V | ||
| 68181-19C00-2WW | EMBLEM, "KATANA" FOR 28V | ||
| 68182-19C10-3AS | EMBLEM FOR 24V | ||
| 68182-19C10-3AU | EMBLEM FOR 28V | ||
| 94631-19C10 | MOLDING | ||
| 1 | 94635-19C00 | MOLDING | 1 |
| 94438-19C00 | JOINT | ||
| 94435-19C00-24V | LID, OIL (BLUE) CLEAR COATING | ||
| 94435-19C01-24V | LID, OIL (BLUE) | ||
| 94435-19C00-28V | LID, OIL (RED) CLEAR COATING | ||
| 94435-19C01-28V | LID, OIL (RED) | ||
| 1 | 09139-06030 | SCREW | 1 |
| 94402-19C40-24V | COVER ASSY, COWLING,LH (BLUE) CLEAR COATING | ||
| 94402-19C41-24V | COVER ASSY, COWLING,LH (BLUE) | ||
| 94402-19C40-28V | COVER ASSY, COWLING,LH (RED) CLEAR COATING | ||
| 94402-19C41-28V | COVER ASSY, COWLING,LH (RED) Includes Item(s) 34 - 39 | ||
| 68190-19C10-71P | TAPE SET, LH FOR 24V | ||
| 68190-19C10-70G | TAPE SET, LH FOR 28V | ||
| 2 | 09139-06029 | SCREW, FRONT | 2 |
| 2 | 09160-06036 | WASHER | 2 |
| 2 | 09139-06030 | SCREW, UPPER | 2 |
| 2 | 09161-06021 | WASHER | 2 |
| 94560-19C00 | BRACKET, UPPER,RH | ||
| 94570-19C00 | BRACKET, UPPER,LH | ||
| 4 | 09125-06055 | SCREW | 4 |
| 94573-19C00 | NUT | ||
| 4 | 09139-06029 | SCREW | 4 |
| 4 | 09160-06036 | WASHER | 4 |
| 4 | 09180-06011 | SPACER | 4 |
| 4 | 09320-09016 | CUSHION | 4 |
| 94471-19C00-24V | COVER, UNDER,RH (BLUE) | ||
| 94471-19C00-28V | COVER, UNDER,RH (RED) | ||
| 94481-19C00-24V | COVER, UNDER,LH (BLUE) | ||
| 94481-19C00-28V | COVER, UNDER,LH (RED) | ||
| 2 | 09139-06042 | SCREW, FRONT | 2 |
| 94531-19C00 | BRACKET, UNDER,RH | ||
| 94532-19C00 | BRACKET, UNDER,LH | ||
| 94590-19C00 | NUT | ||
| 2 | 01137-06165 | BOLT | 2 |
| 2 | 09139-05025 | SCREW (5X14) | 2 |
| 2 | 09161-05017 | WASHER | 2 |
| 2 | 94484-32B00 | NUT | 2 |
| 2 | 09139-06029 | SCREW, REAR | 2 |
| 2 | 09180-06097 | SPACER | 2 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09136-06081 | SCREW, LOWER | 2 |
| 2 | 09180-06011 | SPACER | 2 |
| 2 | 02142-15165 | SCREW, LOWER | 2 |
| 94580-19C00 | BRACKET, LOWER | ||
| 3 | 02142-05164 | SCREW | 3 |
| 3 | 09161-05017 | WASHER | 3 |
| 94475-19C00-24V | COVER, UNDER,FRONT (BLUE) | ||
| 94475-19C00-28V | COVER, UNDER,FRONT (RED) | ||
| 94475-19C01 | COVER, UNDER,FRONT (BLACK) | ||
| 1 | 68612-48B00 | LABEL, SCREEN | 1 |
| 68612-48B10 | LABEL, SCREEN (FRENCH) | ||
| SPECIAL NOTE | REFER TO FIG.40B(H-10) FOR |
