Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 515176755 | Speedometer Ass'y Includes 1 to 4 | 1 |
| 1 | 415129355 | Speedometer Button | 1 |
| 1 | 415129348 | Gauge Ring | 1 |
| 1 | 415129349 | Lens | 1 |
| 1 | 219902677 | BRP Logo 20 mm | 1 |
| 1 | 517304194 | RH Headlamp Ass'y Includes 6 to 10 | 1 |
| 1 | 517304195 | LH Headlamp Ass'y Includes 6 to 10 | 1 |
| 1 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 1 |
| XXXX | Not Available As Spare Part - Bulb Holder | ||
| 2 | 515176498 | Cap | 2 |
| 1 | 515176499 | Cover | 1 |
| 6 | 250000128 | Torx Truss Screw M6 X 20 | 6 |
| 6 | 250000048 | Panel Nut M6 X 1.0 | 6 |
| 1 | 515176815 | Dess Switch Includes 13 to 16 | 1 |
| 3 | 515175232 | Male Terminal | 3 |
| 1 | 515175494 | Male Housing, 3 Circuits | 1 |
| 409902000 | Tubing 12 mm | ||
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 515176461 | DESS Cap | 1 |
| 1 | 278002021 | Voltage Regulator | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 515176751 | Main Harness | ||
| 1 | 515176234 | FEMALE TERMINAL HOUSING, 6 CIRCUITS | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 515176544 | Plate | 1 |
| 515176514 | Fuse Holder | ||
| 1 | 515176637 | PROTECTOR | 1 |
| 1 | 515176472 | Switch Ass'y | 1 |
| 1 | 250000373 | BRASS NUT | 1 |
| 4 | 210262040 | Hex. Flange Screw M6 X 20 | 4 |
| 1 | 210262040 | Hex. Flange Screw M6 X 20 | 1 |
| 5 | 224061121 | Flat Washer | 5 |
| 1 | 515176358 | Ground Wire | 1 |
| 1 | 515176795 | Tie Rap Mount (screwable) | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 515175799 | Visor Plug Harness Includes 42 to 46 | 1 |
| 2 | 515175232 | Male Terminal | 2 |
| 515175172 | OPEN BARREL | ||
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long | 1 |
| 1 | 515175654 | Male Terminal Housing, 2 Circuits | 1 |
| 1 | 572103300 | Cap | 1 |
| 1 | 515175851 | Extension | 1 |
| 1 | 861507200 | Outlet Power Kit, 12 Volts | 1 |
| 515176480 | Motor Ass'y Includes 58 to 60 | ||
| XXXX | Not Available As Spare Part - Male Terminal Housing | ||
| 2 | 515175273 | MALE TERMINAL | 2 |
| 1 | 515176821 | PLATE | 1 |
| 3 | 207662044 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 224061121 | Flat Washer | 1 |
| 515176760 | REVERSE CABLE Includes 64 to 72 | ||
| 4 | 515175232 | Male Terminal | 4 |
| 2 | 515175282 | Female Terminal | 2 |
| 2 | 410113200 | Relay | 2 |
| 2 | 409209900 | Female Housing, 5 Circuits | 2 |
| 10 | 561503100 | FEMALE TERMINAL | 10 |
| 1 | 219704407 | Tubing 10 MM 1000MM Long | 1 |
| 1 | 515175846 | Male Terminal Housing, 4 Circuits | 1 |
| 1 | 515176550 | Female Terminal Housing | 1 |
| 1 | 510004413 | Rocker Switch | 1 |
| 1 | 510004414 | Switch Protector | 1 |
| 1 | 515176705 | Seat Harness Includes 75 to 85 | 1 |
| 5 | 409010100 | Female Terminal | 5 |
| 5 | 409010400 | Female Terminal Housing, 1 Circuit | 5 |
| 5 | 515175231 | Female Terminal | 5 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704399 | Was 409901700 Tubing (9 mm) | 1 |
| 1 | 409012700 | Diode | 1 |
| 1 | 515175658 | Female Housing, 2 Circuits | 1 |
| XXXX | Not Available As Spare Part - Female Terminal Housing (4 Circuits) | ||
| 515176678 | Compressor Module | ||
| 1 | 207663544 | Hex. Flange Screw M6 X 35 | 1 |
| 1 | 234061410 | Flat Washer 6 mm | 1 |
| 1 | 232061414 | Hex. Nut M6 | 1 |
