Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 503193901 | Black, Runner 128" Deep Black | 1 |
| 1 | 503194156 | Yellow, Runner 128" Sunburst Yellow | 1 |
| 1 | 503193902 | Bare, Runner 128" | 1 |
| 1 | 503193962 | Slider 128" | 1 |
| 1 | 208562531 | Phillips Screw M6 X 25 | 1 |
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 2 | 516007816 | Runner Decal | 2 |
| 2 | 503192530 | Slide Protector | 2 |
| 4 | 250200140 | Washer | 4 |
| 2 | 207652544 | Hex. Flange Screw M5 X 25 | 2 |
| 2 | 233251434 | Flange Elastic Nut M5 | 2 |
| 2 | 503190576 | Rubber Stopper | 2 |
| 2 | 503191273 | Washer | 2 |
| 2 | 293150224 | Pop Rivet 3/16 | 2 |
| 2 | 503193717 | Rubber Stopper Ass'y Includes 310 to 310a | 2 |
| 1 | 572084800 | Reinforcement Stopper | 1 |
| 4 | 503191273 | Washer | 4 |
| 2 | 293150013 | Pop Rivet 3/16" | 2 |
| 2 | 503192750 | Rubber Stopper | 2 |
| 2 | 503191316 | Black, Wheel Ass'y 141 mm Package XRS | 2 |
| 2 | 503193477 | Black, Wheel Ass'y 141 mm Except Package XRS | 2 |
| 1 | 503190396 | Ball Bearing | 1 |
| 1 | 415129371 | Retaining Ring | 1 |
| 2 | 503193894 | Casted Support | 2 |
| 2 | 503190434 | Labyrinth Seal | 2 |
| 2 | 503191820 | Wheel Cup M6 | 2 |
| 2 | 250000944 | Hex. Flange Screw M6 X 70 | 2 |
| 2 | 233261466 | Hex. Flange Elastic Nut M6 | 2 |
| 2 | 250000945 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 503192771 | Black, Wheel Cap | 2 |
| 2 | 503192794 | Black, Wheel Ass'y 141 mm Includes 460 to 460b | 2 |
| 2 | 503192766 | Black, Wheel Ass'y 180 mm Includes 600 to 600a | 2 |
| 1 | 503190429 | Rear Axle | 1 |
| 1 | 503190430 | Spacer | 1 |
| 1 | 503190432 | Washer | 1 |
| 3 | 503190428 | Rear Wheel Spacer | 3 |
| 1 | 503194050 | Black, Wheel Ass'y 180 mm Includes 670 to 670b | 1 |
| 1 | 503190682 | Labyrinth Seal | 1 |
| 3 | 503190434 | Labyrinth Seal | 3 |
| 2 | 503191910 | Washer | 2 |
| 2 | 234201474 | Conical Spring Washer 10 mm | 2 |
| 2 | 250000817 | Hex Screw With Nilon Patch, M10 X 35 | 2 |
| 2 | 503191183 | Spring Support | 2 |
| 2 | 503190754 | Retainer Cushion | 2 |
| 2 | 205082554 | Socket Screw M8 X 25 | 2 |
| 2 | 233281466 | Elastic Flange Nut M8 | 2 |
| 2 | 503192583 | Tensioner | 2 |
| 2 | 503193250 | Spacer | 2 |
| 2 | 230100054 | Hex Screw M10 x 100 | 2 |
| 2 | 233601466 | Elastic Locking Nut M10 | 2 |
| 4 | 207063054 | Hex. Cap Screw M6 X 30 | 4 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 | 4 |
| 1 | 503191260 | Axle Strap | 1 |
| 1 | 503192678 | Spacer | 1 |
| 2 | 250200143 | Flat Washer | 2 |
| 2 | 205503554 | Socket Head Screw M10 X 35 | 2 |
| 1 | 503192759 | Stopper Strap | 1 |
| 2 | 250200128 | Flat Washer 8 mm | 2 |
| 1 | 207683044 | Hex. Flange Screw M8 X 30 | 1 |
| 1 | 233281466 | Elastic Flange Nut M8 | 1 |
| 1 | 503193435 | Pivot Axle | 1 |
| 2 | 503191259 | Center Bushing | 2 |
| 4 | 250200143 | Flat Washer | 4 |
| 1 | 503193227 | Bolt M10 X 251MM | 1 |
| 1 | 233201466 | Flange Elastic Nut M10 | 1 |
| 2 | 503192496 | Washer | 2 |
| 1 | 503194529 | Front Arm Ass'y | 1 |
| 2 | 503190698 | Axle | 2 |
| 2 | 503191926 | Washer | 2 |
| 2 | 207006056 | Hex. Cap Screw M10 X 60 | 2 |
| 2 | 503191966 | Lower Axle | 2 |
| 2 | 503190656 | Washer | 2 |
| 2 | 503192491 | Washer | 2 |
| 2 | 250000537 | Hex. Cap Screw M12 X 35 | 2 |
| 1 | 503193617 | Rear Arm Ass'y Without Quick Adjust System | 1 |
| 1 | 503193618 | Rear Arm Ass'y Quick Adjust System | 1 |
| 1 | 232061404 | Hexagonal Nut M6 | 1 |
| 2 | 503192767 | Bushing | 2 |
| 4 | 503191555 | Swivel Bushing | 4 |
| 2 | 503191640 | Cushion | 2 |
| 1 | 503192981 | Lower Shaft | 1 |
| 1 | 503192823 | Pivot Arm Ass'y Includes 3000f to 3000m | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 2 | 517225900 | Flat Washer | 2 |
| 1 | 408200700 | Grease Fitting | 1 |
| 2 | 232551414 | Elastic Stop Nut M5 | 2 |
| 2 | 205041060 | Socket Head Screw M4X 10 | 2 |
| 2 | 503192749 | Guide Block | 2 |
| 1 | 503192918 | LH Cam Block | 1 |
| 1 | 503192919 | RH Cam Block | 1 |
| 2 | 205523554 | Socket Head Screw M12 X 35 | 2 |
| 1 | 503191565 | LH Cam Adjuster Without Quick Adjust System | 1 |
| 2 | 503192921 | O-Ring Quick Adjust System | 2 |
| 1 | 503191566 | RH Cam Adjuster Without Quick Adjust System | 1 |
| 1 | 516004900 | LH Block Sticker Decal Quick Adjust System | 1 |
| 2 | 293370013 | E-Circlip Without Quick Adjust System | 2 |
| 1 | 516004901 | RH Block Sticker Decal Quick Adjust System | 1 |
| 2 | 503192921 | O-Ring Without Quick Adjust System | 2 |
| 1 | 516004900 | LH Block Sticker Decal Without Quick Adjust System | 1 |
| 1 | 516004901 | RH Block Sticker Decal Without Quick Adjust System | 1 |
| 1 | 503192105 | Black Lh Spring SKU MXKN | 1 |
| 1 | 503193158 | Black, LH Spring Square Except SKU - MXKN | 1 |
| 1 | 503192104 | Black, RH Spring Square SKU MXKN | 1 |
| 1 | 503193159 | Black, RH Spring Square Except SKU - MXKN | 1 |
| 2 | 503192808 | Black Wheel Ass'y 155 mm Includes 3070 to 3070b | 2 |
| 2 | 503189146 | Axle Spring | 2 |
| 2 | 503192592 | Labyrinth Ring | 2 |
| 2 | 503193069 | Link Ass'y Includes 3100 to 3100c | 2 |
| 1 | 503192494 | Washer | 1 |
| 2 | 503191555 | Swivel Bushing | 2 |
| 2 | 293370080 | Retaining Ring | 2 |
| 2 | 207204056 | Cap Screw Hex. M10 X 40 | 2 |
| 1 | 503189156 | Pivot Arm Axle | 1 |
| 4 | 503192494 | Washer | 4 |
| 1 | 503192440 | Bolt M8 X 248mm | 1 |
| 2 | 503193903 | Rod Link | 2 |
| 1 | 503190643 | Axle Bar (Long) | 1 |
| 2 | 503192494 | Washer | 2 |
| 1 | 503193372 | Screw M8 X 90 | 1 |
| 2 | 503192555 | Axle Bar | 2 |
| 2 | 234082410 | Flat Washer 8 mm | 2 |
| 2 | 207085556 | Hex. Screw M8 X 55 | 2 |
| 2 | 503192606 | Rear Shock Axle | 2 |
| 2 | 505072663 | Leg Cushion | 2 |
| 2 | 207684044 | Hex. Flange Screw M8 X 40 | 2 |
| 1 | 503193777 | Hydraulic Adjuster Ass'y Quick Adjust System | 1 |
| 1 | 503193490 | Master Cylinder Ass'y Quick Adjust System | 1 |
| 1 | 293300036 | O-Ring Quick Adjust System | 1 |
| 1 | 250400014 | Spring Pin Quick Adjust System | 1 |
| 1 | 516004917 | Adjustment Decal Quick Adjust System | 1 |
| 1 | 503193778 | Actuator Ass'y Quick Adjust System | 1 |
| 1 | 503192795 | Cylinder Quick Adjust System | 1 |
| 1 | 503193779 | Piston Quick Adjust System | 1 |
| 1 | 503192633 | Spring Bracket Quick Adjust System | 1 |
| 1 | 503193485 | Holder Quick Adjust System | 1 |
| 2 | 293300068 | O-Ring Quick Adjust System | 2 |
| 1 | 503192832 | O-Ring Quick Adjust System | 1 |
| 1 | 293300039 | O-Ring Quick Adjust System | 1 |
| 1 | 503192833 | Wear Ring Quick Adjust System | 1 |
| 1 | 503192834 | Retaining Ring Quick Adjust System | 1 |
| 1 | 503193014 | O-Ring Quick Adjust System | 1 |
| 1 | 503193476 | Connector Hose Quick Adjust System | 1 |
| 4 | 705601628 | Copper Washer Quick Adjust System | 4 |
| 2 | 705600628 | Banjo Bolt Quick Adjust System | 2 |
| 2 | 293250269 | O-Ring Quick Adjust System | 2 |
| 503192825 | WIPER SEAL Quick Adjust System | ||
| 1 | 503193056 | Knob Adjuster Ass'y Quick Adjust System | 1 |
| 516004751 | STICKER KNOB ADJUSTER Quick Adjust System | ||
| 1 | 205541660 | Socket Screw M4 X 16 (Scotch Grip) Quick Adjust System | 1 |
| 1 | 503194686 | LH Support Quick Adjust System | 1 |
| 1 | 516006369 | Decal Quick Adjust System | 1 |
| 1 | 503194524 | LH Hose Protector Quick Adjust System | 1 |
| 1 | 503193413 | Plate Quick Adjust System | 1 |
| 3 | 293150144 | Stavex Rivet Quick Adjust System | 3 |
| 4 | 234061600 | Stainless Flat Washer M6 Quick Adjust System | 4 |
| 4 | 205062560 | Socket Head Screw M6 X 25 Quick Adjust System | 4 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 Quick Adjust System | 4 |
| 1 | 503192956 | LH Half Housing Quick Adjust System | 1 |
| 4 | 205062060 | Socket Head Screw M6 X 20 Quick Adjust System | 4 |
| 1 | 503194685 | RH Support Quick Adjust System | 1 |
| 1 | 503194525 | RH Hose Protector Quick Adjust System | 1 |
| 1 | 503192957 | RH Half-Housing Quick Adjust System | 1 |
| 2 | 293250085 | O-Ring Quick Adjust System | 2 |
| 2 | 234061600 | Stainless Flat Washer M6 Quick Adjust System | 2 |
| 2 | 205062060 | Socket Head Screw M6 X 20 Quick Adjust System | 2 |
| 1 | 503194113 | Protector Quick Adjust System | 1 |
| 1 | 224061201 | Flat Washer Quick Adjust System | 1 |
| 1 | 207662556 | Hex. Flange Screw M6 X 25 Quick Adjust System | 1 |
| 1 | 233261466 | Hex. Flange Elastic Nut M6 Quick Adjust System | 1 |
| 1 | 503193025 | Adjustment Knob Ass'y Quick Adjust System | 1 |
| 1 | 516004752 | Shock Knob Adjustment Decal Quick Adjust System | 1 |
| 1 | 250000644 | Allen Screw M3 X 0.5 X 10 Quick Adjust System | 1 |
| 1 | 503193166 | Plate Quick Adjust System | 1 |
| 1 | 205961060 | Socket Head Screw M6 X 10, Scotch Grip Quick Adjust System | 1 |
| 2 | 503192771 | Black, Wheel Cap Not Shown | 2 |
