Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 512059107 | Handle Ass'y 28 mm Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 512059109 | Throttle Handle Housing Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 732601143 | Flange Screw Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 1 | 414440800 | Socket Set Screw M8 X 10 Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 515175410 | Kill Switch Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 572100901 | Switch Cover Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 512059388 | Throttle Cable Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 414753300 | Washer Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 414753500 | Circlip Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 414274500 | Circlip Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 512059110 | CHOKE CABLE Includes 12 - 13. Formula Deluxe 600. Formula Deluxe 700. | ||
| 394103300 | Lock Washer, Interior Teeth Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 515175220 | Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 512059094 | PLASTIC NUT Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 515175170 | Fuel Sensor Ass’Y Includes 16 - 19. (GSE/GS) Formula Deluxe 600. Formula Deluxe 700. | ||
| 409204500 | MALE HOUSING (GSE/GS) Formula Deluxe 600. Formula Deluxe 700. | ||
| 409210000 | MALE TERMINAL Formula Deluxe 600. Formula Deluxe 700. | ||
| 410112400 | Fuse, 0.25 Ampere Formula Deluxe 600. Formula Deluxe 700. | ||
| 5 | 232551414 | Elastic Stop Nut M5 Formula Deluxe 600. Formula Deluxe 700. | 5 |
| 1 | 409204600 | FEMALE TERMINAL HOUSING, 24 CIRCUITS Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 561503100 | FEMALE TERMINAL Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 513032987 | Fuel Tank Formula Deluxe 600. | ||
| 513032988 | Fuel Tank Formula Deluxe 600. Formula Deluxe 700. | ||
| 513032988 | Fuel Tank Formula Deluxe 700. | ||
| 1 | 513032901 | Fuel Tank Cap Formula Deluxe 600. | 1 |
| 1 | 572039600 | Cap-Fuel Tank Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 513032908 | Grommet Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 414814100 | Male Connector Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 219704409 | Was 415080100 Fuel Line Primer 3,2mm Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 513032923 | TUBE CLAMP Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 414818200 | SPRING Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 414872100 | Fuel Filter Strainer Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 415005700 | Hose Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 513033010 | Norma Spring Clamp Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 1 | 414872700 | Male Connector Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 570273900 | Grommet Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 513032979 | UNIVERSAL SPRING CLAMP Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 1 | 513032903 | Formed Hose Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 415018200 | CLIP Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 1 | 390406500 | Pop Rivet 3/16" Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 403901804 | Fuel Pump Formula Deluxe 600. Formula Deluxe 700. | ||
| 210361280 | HEX. SCREW M6 X 12 Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 219704439 | Hose 1/4 1000Mm Long - Call Your Local BRP Dealership Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 414415200 | Spring Clamp Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 513032986 | Formed Tube Formula Deluxe 600. Formula Deluxe 700. | ||
| 1 | 219704407 | Tubing 10 MM 1000MM Long Formula Deluxe 600. Formula Deluxe 700. | 1 |
| 2 | 414420700 | Spring Clamp Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 2 | 234082410 | Flat Washer 8 mm Formula Deluxe 600. Formula Deluxe 700. | 2 |
| 2 | 232581414 | Hex. Elastic Stop Nut M8 Formula Deluxe 600. Formula Deluxe 700. | 2 |
