Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 420931589 | DOUBLE GASKET 0.8 MM Formula Deluxe 500. | 1 |
| 1 | 420931584 | Double Gasket 0.8 mm Formula Deluxe 600. | 1 |
| 1 | 420931960 | DOUBLE GASKET 0.7 MM Formula Deluxe 500. | 1 |
| 1 | 420931962 | Gasket 0.7 mm Formula Deluxe 600. | 1 |
| 1 | 420931587 | DOUBLE GASKET 0.6 MM Formula Deluxe 500. | 1 |
| 1 | 420931582 | Gasket 0.6 mm Formula Deluxe 600. | 1 |
| 1 | 420931588 | DOUBLE GASKET 0.5 MM Formula Deluxe 500. | 1 |
| 1 | 420931583 | Double Gasket 0.5 mm Formula Deluxe 600. | 1 |
| 420923855 | Cylinder with Sleeve Formula Deluxe 500. | ||
| 421000568 | REBUILD-CYLINDER 493 2000 | ||
| 2 | 420923437 | Cylinder with Sleeve Formula Deluxe 600. | 2 |
| 420854490 | EXHAUST VALVE Formula Deluxe 500. | ||
| 2 | 420854370 | Exhaust Valve Formula Deluxe 600. | 2 |
| 1 | 420430110 | O-Ring Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420950730 | Oil Seal Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 2 | 420250239 | Gasket Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 420854265 | Valve Housing Formula Deluxe 500. Formula Deluxe 600. | ||
| 1 | 420854266 | Valve Housing Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 4 | 205062044 | Socket Head Screw M6 X 20 Formula Deluxe 500. Formula Deluxe 600. | 4 |
| 2 | 290260723 | Bellows Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 2 | 420838253 | Spring Clamp Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 2 | 420854449 | Exhaust Valve Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 2 | 290239048 | Hose Spring Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 420239948 | SPRING Formula Deluxe 500. | ||
| 2 | 420239944 | Spring Formula Deluxe 600. | 2 |
| 1 | 420911551 | Valve Cover Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420911552 | Valve Cover Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 2 | 420241221 | Adjuster Screw Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 1 | 420838083 | SPRING CLIP Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420841555 | Hex. Tapping Screw M5 X 20 Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 8 | 420640951 | Hex. Screw M8 X 68.5 Formula Deluxe 500. Formula Deluxe 600. | 8 |
| 2 | 420931590 | Rubber Ring Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 2 | 420831792 | O-Ring Formula Deluxe 500. | 2 |
| 2 | 293300026 | O-Ring Formula Deluxe 600. | 2 |
| 420923880 | Cylinder Head (Silver) Formula Deluxe 500. | ||
| 420923452 | CYLINDER HEAD, SILVER Formula Deluxe 600. | ||
| 1 | 290950320 | O-Ring Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 2 | 420430782 | O-Ring Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 1 | 420923460 | Cylinder Head Cover, Silver Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 10 | 420841306 | Hex. Collar Screw M8 X 65 Formula Deluxe 500. Formula Deluxe 600. | 10 |
| 2 | 420941621 | Hex. Collar Screw M8 X 56.5 Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 1 | 420922515 | Thermostat (42 Deg.) Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420931270 | SEALING RING Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420922025 | BENT OUTLET SOCKET Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 3 | 420941250 | Hex. Tapping Screw M6 X 20 Formula Deluxe 500. Formula Deluxe 600. | 3 |
| 1 | 420850338 | Gasket Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 1 | 420922062 | BENT OUTLET SOCKET Formula Deluxe 500. Formula Deluxe 600. | 1 |
| 420240480 | PLUG SCREW Formula Deluxe 500. Formula Deluxe 600. | ||
| 420941451 | HEX. COLLAR SCREW M6 X 40 Formula Deluxe 500. Formula Deluxe 600. | ||
| XXXX | Not Available As Spare Part - Gasket Ring Formula Deluxe 500. | ||
| XXXX | Not Available As Spare Part - Plug Screw M12 x 1.5 Formula Deluxe 500. | ||
| 2 | 420924519 | Reed Valve Ass'y Includes 35 - 39. Formula Deluxe 500. Formula Deluxe 600. | 2 |
| XXXX | Not Available As Spare Part - Reed Valve Housing Formula Deluxe 500. Formula Deluxe 600. | ||
| 4 | 420924532 | Reed Pedal Formula Deluxe 500. Formula Deluxe 600. | 4 |
| 4 | 420924539 | Reed Pedal Stop Formula Deluxe 500. Formula Deluxe 600. | 4 |
| 12 | 420941215 | Phillips Screw M3 X 5 Formula Deluxe 500. Formula Deluxe 600. | 12 |
| 420867860 | CARBURETOR SOCKET Formula Deluxe 500. | ||
| 420867880 | Carburetor Socket Formula Deluxe 600. | ||
| 12 | 420941925 | Tapping Screw M5 X 16 Formula Deluxe 500. Formula Deluxe 600. | 12 |
| 2 | 420851440 | CLAMP Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 420867815 | Intake Resonator Formula Deluxe 500. | ||
| 420867817 | Intake Resonator Formula Deluxe 600. | ||
| 420931615 | GASKET Formula Deluxe 500. | ||
| 2 | 420931610 | Gasket Formula Deluxe 600. | 2 |
| 420973650 | Exhaust Manifold Formula Deluxe 500. | ||
| 420979543 | Exhaust Manifold Formula Deluxe 600. | ||
| 420888721 | Engine Gasket Set Formula Deluxe 500. | ||
| 420888582 | Engine Gasket Set Formula Deluxe 600. | ||
| 420888726 | CYLINDER GASKET SET Formula Deluxe 500. | ||
| 1 | 420888587 | Cylinder Gasket Set Formula Deluxe 600. | 1 |
| 6 | 205082544 | Socket Head Screw M8 X 25 Formula Deluxe 500. Formula Deluxe 600. | 6 |
| 2 | 207182044 | Hex. Screw M8 X 20 Formula Deluxe 500. Formula Deluxe 600. | 2 |
| 8 | 234181401 | Lock Washer 8 mm Formula Deluxe 500. Formula Deluxe 600. | 8 |
| 1 | 413710300 | Loctite 17914, Sealant, 80 ml | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 711297433 | Molykote G-n Paste, Dow Corning, 88162-74, 50g 88162-74, 50 g | 1 |
| 1 | 413707000 | Dow Corning 111, 150 g | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
