Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504153498 | Chaincase Ass'y | 1 |
| 1 | 861805514 | Kit Plate Ass'y | 1 |
| 4 | 233261434 | Flange Elastic Nut M6 | 4 |
| 1 | 504082900 | Washer | 1 |
| 1 | 250000740 | Torx Screw M8 X 20, Scotch Grip | 1 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 1 | 293200168 | Oil Seal | 1 |
| 1 | 293350115 | Ball Bearing | 1 |
| 1 | 504152576 | Circlip | 1 |
| 1 | 504153727 | Sprocket 24 Teeth Ass'y Includes 140 to 140a | 1 |
| 1 | 293350123 | Bearing Needle | 1 |
| 1 | 504153500 | Connecting Shaft Ass'y | 1 |
| 1 | 293370183 | External Retaining Ring | 1 |
| 1 | 504153179 | Spring Release | 1 |
| 1 | 504153502 | Sliding Gear 27 Teeth Machined | 1 |
| 1 | 504152689 | Washer | 1 |
| 1 | 293370055 | Circlip | 1 |
| 1 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 1 |
| 1 | 504153519 | Axle Reverse Ass'y Includes 500 to 500a | 1 |
| 1 | 250400010 | Rolled Pin M3 X 10 | 1 |
| 1 | 504078700 | Ring | 1 |
| 1 | 504153736 | Sprocket 19 Teeth Ass'y | 1 |
| 1 | 570048600 | Alignement Rod | 1 |
| 1 | 504153738 | Gear Straight 29 Teeth Ass'y | 1 |
| 1 | 504077300 | Spacer | 1 |
| 1 | 293200159 | Oil Seal | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504152581 | Sprocket, 49 Teeth | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 293300201 | O-Ring | 1 |
| 1 | 504153696 | Magnetic Cap Ass'y Includes 1160 to 1160a | 1 |
| 1 | 504153697 | Magnetic Cap | 1 |
| 1 | 504153266 | Drive Chain, 110 Links | 1 |
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504153760 | Adjustment Screw | 1 |
| 1 | 250500012 | Allen Drive Plug 1/8-27 PTF | 1 |
| 1 | 504153704 | Magnetic Plug | 1 |
| 1 | 293300202 | O-Ring | 1 |
| 1 | 504153559 | Tensioner | 1 |
| 1 | 504153312 | Slider Chain | 1 |
| 1 | 250200185 | Copper Washer | 1 |
| 1 | 293370105 | Circlip | 1 |
| 1 | 250000717 | Torx Head Screw M6 X 16 | 1 |
| 1 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
| 1 | 504153503 | Chaincase Cover Ass'y Includes 1700 to 1700c | 1 |
| 1 | 515178223 | Clip Connector | 1 |
| 1 | 415130141 | Braided Sleeve | 1 |
| 1 | 293300199 | O-Ring | 1 |
| 8 | 250001012 | Torx T-30 Pan HD Taptite M6X20 | 8 |
| 1 | 504152930 | Cap | 1 |
| 1 | 293710035 | Straight Fitting | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 504152900 | Protector Tube | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 504153590 | Fork Ass'y | 1 |
| 1 | 504153508 | Axle Reverse | 1 |
| 2 | 250400045 | Spring Pin M5 X 16 | 2 |
| 1 | 504153532 | Machined Lever | 1 |
| 1 | 207564044 | Hex. Flange Screw M6 X 40, Scotch Grip | 1 |
| 1 | 504153657 | Rod Actuating Adjustable Ass'y | 1 |
| 1 | 504153707 | Rod Actuating Ass'y Enduro | 1 |
| 1 | 504153944 | Rod Actuating Ass'y Adrenaline | 1 |
| 1 | 207562544 | Hex. Flange Screw M6 X 25 Enduro | 1 |
| 1 | 205562044 | Socket Head Screw M6 X 20, Scotch Grip | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 Enduro | 1 |
| 1 | 207562544 | Hex. Flange Screw M6 X 25 Adrenaline | 1 |
| 1 | 504153524 | Reverse Lever Adrenaline | 1 |
| 1 | 205564044 | Socket Head Screw M6 X 40, S.GRIP Adrenaline | 1 |
| 1 | 207089044 | Hex. Screw M8 X 90 | 1 |
| 2 | 207562544 | Hex. Flange Screw M6 X 25 Adrenaline | 2 |
| 1 | 504153683 | Handle Support Adrenaline | 1 |
| 1 | 504153648 | Spacer Adrenaline | 1 |
| 2 | 504153735 | Bushing Adrenaline | 2 |
| 1 | 207562544 | Hex. Flange Screw M6 X 25 | 1 |
| 2 | 504153735 | Bushing | 2 |
| 1 | 504153648 | Spacer | 1 |
| 1 | 504153695 | Bearing Housing Ass'y | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 504153830 | Axle Drive Ass'y Includes 3000 to 3000b | 1 |
| 1 | 504153426 | Retaining Ring | 1 |
| 1 | 504153101 | Track Ass'y 15" X 137" X 1.25" Enduro | 1 |
| 1 | 504152905 | Track Ass'Y 15X137X1.2 Adrenaline North America | 1 |
| 504154115 | Track Ass'y 15" X 137" X 1.5RS" Adrenaline Europe | ||
| 32 | 415129528 | Track Guide Enduro | 32 |
| 64 | 415129529 | Cleat Enduro | 64 |
| 64 | 504152651 | Cleat Adrenaline North America | 64 |
| 64 | 415129529 | Cleat Adrenaline Europe | 64 |
