Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 2204143 | HEADLIGHT HARNESS KIT | 1 |
| 3280363 | 6 PULSE SPEEDOMETER, 3.38 IN [AA] | ||
| 3280358 | 6 PULSE SPEEDOMETER, 3.38 IN [DA] | ||
| 4010315 | INDICATOR PANEL | ||
| 3 | 4010416 | INDICATOR BULB, HOBBS | 3 |
| 1 | 7511881 | SCREW | 1 |
| ------- | ASM., THROTTLE CONTROL [See Controls - Throttle Asm./Cable Pg. B7, Ref. 5] | ||
| 1 | 5244581-067 | HANDLEBAR TUBE, MEDIUM GLOSS BL | 1 |
| 2200774 | Discontinued [Incl. Blocks and 6,10,28] | ||
| 5630616-067 | Discontinued | ||
| 7541933 | NUT | ||
| 7555868 | WASHER, LOCK,(S.S.) | ||
| 2 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 2 |
| 4 | 7515189 | SCREW | 4 |
| 3280291 | CLAMP,BACK,ELEC.SPEEDO,3.38" | ||
| 5433763-195 | POD-HEADLIGHT,UPPER,OLIVE GRN | ||
| ------- | ASM., MASTER CYLINDER [See Controls - RH, Master Cylinder/Brake Line Pg. B9 for details] | ||
| 5433903 | SWITCH SPACER, LEFT | ||
| 1 | 4010422 | HI/LO/MODE HANDLEBAR SWITCH | 1 |
| 2 | 5433834-070 | HANDLEBAR GRIP, 7/8 ID, GLOSS B | 2 |
| 1 | 5432952 | PLUG, HOLE | 1 |
| 1 | 7517625 | SCREW, SET | 1 |
| 1 | 5244969-067 | POD MOUNTING BRACKET, BLACK | 1 |
| 2 | 7517317 | SCREW | 2 |
| 1 | 4032079 | ADJUSTING KNOB | 1 |
| 1 | 2410268 | HEADLAMP ASSEMBLY, 50 WATT | 1 |
| 1 | 4010253 | 50 WATT HEADLIGHT BULB | 1 |
| 4032078 | Discontinued | ||
| 2 | 5410163 | O-RING | 2 |
| 1 | 7081008 | FRICTION CHOKE CABLE, 40 IN | 1 |
| 4 | 7542122 | NYLOK NUT | 4 |
| 4010283 | RECEPTACLE-POD MNT,12 VOLT | ||
| 7080631 | Discontinued | ||
| 5433762-070 | Discontinued | ||
| 1 | 4010390 | SWITCH-KEY 3 POS UNSEALED [Incl. Key] | 1 |
| 1 | 4010278 | KEYBLANK-B,6700-6800,2000-2100 NOTE: Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 4010321 | KEYBLANK-A,2700-2800,2200-2389 NOTE: Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 5433534 | KEY COVER-KEYSWITCH | 1 |
| 1 | 5433733 | IGNITION SWITCH NUT | 1 |
| 1 | 7080922 | CHOKE NUT, 24 MM X 1.5 MM | 1 |
| 1 | 5132382 | HALL SENSOR CAP | 1 |
| 1 | 4010298 | HALL EFFECT SENSOR | 1 |
| 1 | 7517658 | SCREW | 1 |
| 1 | 7670127 | #8-10 PANEL CLIP SCREW | 1 |
