Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8FP-47541-00-00 | HOUSING, CHAIN | 1 |
| 2 | 93306-20601-00 | BEARING | 1 |
| 3 | 93306-20592-00 | BEARING | 1 |
| 4 | 93102-40014-00 | OIL SEAL | 1 |
| 5 | 93102-35010-00 | OIL SEAL | 1 |
| 6 | 99009-62500-00 | CIRCLIP | 1 |
| 7 | 99009-52500-00 | CIRCLIP | 1 |
| 8 | 8FP-47558-00-00 | RING, HOUSING | 1 |
| 9 | 90101-10357-00 | BOLT | 1 |
| 10 | 95307-10700-00 | NUT | 1 |
| 11 | 93210-25071-00 | O-RING | 1 |
| 12 | 90387-2508C-00 | COLLAR | 1 |
| 13 | 93210-29282-00 | O-RING | 1 |
| 14 | 90387-30004-00 | COLLAR | 1 |
| 15 | 97007-08014-00 | BOLT | 1 |
| 16 | 90210-08017-00 | WASHER, SEAL | 1 |
| 17 | 8CW-1761A-00-00 | SHAFT, 1 | 1 |
| 18 | 8CW-47591-00-00 | PLATE | 1 |
| 19 | 90105-060A6-00 | BOLT, FLANGE | 2 |
| 20 | 90201-106H5-00 | WASHER, PLATE | 1 |
| 21 | 8FR-47543-00-00 | CAP, HOUSING | |
| 22 | 93306-20511-00 | BEARING | 1 |
| 23 | 93102-35473-00 | OIL SEAL | 1 |
| 24 | 90179-10679-00 | NUT | 2 |
| 25 | 99009-52500-00 | CIRCLIP | 1 |
| 26 | 93606-20044-00 | PIN, DOWEL | 2 |
| 27 | 8FG-18511-00-00 | FORK, SHIFT 1 | 2 |
| 28 | 8ER-18197-00-00 | SHAFT | |
| 29 | 91609-50022-00 | PIN, SPRING | 2 |
| 30 | 93210-12131-00 | O-RING | 1 |
| 31 | 8ER-18198-00-00 | LEVER | 1 |
| 32 | 90387-0608T-00 | COLLAR | 1 |
| 33 | 90201-06071-00 | WASHER, PLATE | 2 |
| 34 | 95817-06040-00 | BOLT, FLANGE | 1 |
| 35 | J45-23845-00-00 | JOINT, UNIVERSAL 2 | 2 |
| 36 | 88T-18157-00-00 | JOINT 2 | 2 |
| 37 | 95607-06200-00 | NUT, SELF U-FLANGE | 3 |
| 38 | 26H-18115-00-00 | ROD, SHIFT | 2 |
| 39 | 95304-06600-00 | NUT | 2 |
| 40 | 90170-06289-00 | NUT | 2 |
| 41 | 95607-06200-00 | NUT, SELF U-FLANGE | 1 |
| 42 | 90105-08748-00 | BOLT, FLANGE | 3 |
| 43 | 95827-10045-00 | BOLT, FLANGE | 3 |
| 44 | 95827-10090-00 | BOLT, FLANGE | 2 |
| 45 | 8ES-47613-00-00 | HOLDER | 1 |
| 46 | 93311-32685-00 | BEARING | 1 |
| 47 | 90387-22005-00 | COLLAR | 1 |
| 48 | 99009-26400-00 | CIRCLIP | 2 |
| 49 | 90201-266P2-00 | WASHER, PLATE | 1 |
| 50 | 8FA-47546-00-00 | LEVEL, OIL | 1 |
| 51 | 90387-30005-00 | COLLAR | 1 |
| 52 | 8FA-17682-20-00 | SPROCKET, CHAIN DRIVE (22T) | 1 |
| 53 | 90208-28001-00 | WASHER, CONICAL SPRING | |
| 54 | 90170-28009-00 | NUT | 1 |
| 55 | 94890-09070-00 | CHAIN (70L) | 1 |
| 56 | 8FB-47587-90-00 | SPROCKET, CHAIN DRIVEN (39T) | 1 |
| 57 | 93317-33179-00 | BEARING | 1 |
| 58 | 90387-2008G-00 | COLLAR | 1 |
| 59 | 90201-320S3-00 | WASHER, PLATE | 1 |
| 60 | 90105-10068-00 | BOLT, FLANGE | 1 |
| 61 | 90387-25009-00 | COLLAR | 1 |
| 62 | 90113-06064-00 | BOLT, SET | 1 |
| 63 | 8FB-17692-00-00 | SPROCKET, DRIVE (18T) | 1 |
| 64 | 93317-21578-00 | BEARING | 1 |
| 65 | 90501-060A1-00 | SPRING, COMPRESSION | 1 |
| 66 | 8CW-17143-00-00 | GEAR, REVERSE PINION 1 (18T) | 1 |
| 67 | 93317-21578-00 | BEARING | 1 |
| 68 | 90201-16245-00 | WASHER, PLATE | 2 |
| 69 | 90105-060A6-00 | BOLT, FLANGE | 1 |
| 70 | 90210-06006-00 | WASHER, SEAL | 1 |
| 71 | 8CW-47571-00-00 | JOURNAL 1 | 1 |
| 72 | 8CW-17243-00-00 | GEAR, REVERSE WHEEL 1 (50T) | 1 |
| 73 | 8CW-17492-00-00 | DOG, TRANSMISSION SHIFT | 1 |
| 74 | 90501-066J5-00 | SPRING, COMPRESSION | 5 |
| 75 | 93440-39175-00 | CIRCLIP | 1 |
| 76 | 90501-260A0-00 | SPRING, COMPRESSION | 1 |
| 77 | 8CW-47564-01-00 | COLLAR | 1 |
| 78 | 8ER-18112-01-00 | ARM, SHIFT | 1 |
| 79 | 8ER-18161-00-00 | GUIDE, PLATE STOPPER | 1 |
| 80 | 99009-18400-00 | CIRCLIP | 1 |
| 81 | 90501-130A0-00 | SPRING, COMPRESSION | 1 |
| 82 | 90387-06059-00 | COLLAR | 1 |
| 83 | 8ER-18174-00-00 | KNOB, SHIFT LEVER | 1 |
| 84 | 90249-06002-00 | PIN | 1 |
| 85 | 93410-06053-00 | CIRCLIP | 2 |
| 86 | 90201-067F9-00 | WASHER, PLATE | 1 |
| 87 | 8ER-1811A-01-00 | PLATE, SHIFT ARM | 1 |
| 88 | 95607-06200-00 | NUT, SELF U-FLANGE | 1 |
| 89 | J51-82817-00-00 | SWITCH | 1 |
| 90 | 98907-04020-00 | SCREW, BIND | 1 |
| 91 | 95607-04100-00 | NUT, U | 1 |
| 92 | 95827-08020-00 | BOLT, FLANGE | 3 |
| 93 | 95607-06200-00 | NUT, SELF U-FLANGE | 1 |
