Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8GL-21940-00-00 | Front Frame Comp | 1 |
| 1 | 8GL-2194E-00-00 | Bracket, Engine | 1 |
| 3 | 90185-08054-00 | Nut, Self-Locking | 3 |
| 12 | 95827-08016-00 | Bolt, Flange | 12 |
| 1 | 90201-086A3-00 | Washer, Plate | 1 |
| 8GL-21950-00-00 | Rear Frame Comp | ||
| 8GL-27452-00-00 | . Bracket, Footrest 1 | ||
| 8GL-27462-00-00 | . Bracket, Footrest 2 | ||
| 1 | 8GL-21926-00-00 | . Reinforcement, Footrest 1 | 1 |
| 8GL-21936-00-00 | . Reinforcement, Footrest 2 | ||
| 1 | 8GL-21925-00-00 | . .Reinf., Housing 1 | 1 |
| 8GL-21930-00-00 | . Housing, Reinf Sub-Assy (R.H) | ||
| 1 | 93306-20601-00 | . . Bearing | 1 |
| 1 | 99009-62500-00 | . . Circlip | 1 |
| 1 | 93102-30012-00 | . . Oil Seal | 1 |
| 1 | 8GL-12440-00-00 | . .Heat Exchanger Assy | 1 |
| 1 | 8GL-21915-00-00 | . .Panel, Sub Frame 4 | 1 |
| 1 | 8GL-21963-00-00 | . Patch 3 | 1 |
| 1 | 8GL-21964-00-00 | . Patch 4 | 1 |
| 1 | 8GL-21943-00-00 | . ..Bracket, Main Track 1 | 1 |
| 1 | 8GL-21953-00-00 | . ..Bracket, Main Track 2 | 1 |
| 2 | 8FU-21919-00-00 | . ..Bracket, Main Track 3 | 2 |
| 1 | 8GL-21944-00-00 | . Bracket, Rear Track Suspensio | 1 |
| 1 | 8GL-21954-00-00 | . Bracket, Rear Track Suspensio | 1 |
| 2 | 90201-10064-00 | . .Washer, Plate | 2 |
| 2 | 95812-10020-00 | . Bolt, Flange | 2 |
| 1 | 8GL-2194H-00-00 | . ..Protector, Muffler | 1 |
| 1 | 8GL-2197N-00-00 | . ..Bracket 7 | 1 |
| 1 | 8GL-21923-00-00 | . ..Reineforcement, Frame Rear | 1 |
| 2 | 8CR-2194N-00-00 | . .Bracket, Fuel Tank 1 | 2 |
| 1 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow QTY:194 | 1 |
| 4 | 8GL-22512-00-00 | . ..Bracket 8 | 4 |
| 2 | 92012-08016-00 | . Bolt, Button Head | 2 |
| 8 | 95022-08016-00 | . Bolt, Flange | 8 |
| 1 | 8HB-21927-00-00 | . Reinforcement, Rear Footrest | 1 |
| 8HB-21937-00-00 | . Reinforcement, Rear Footrest | ||
| 1 | 8GL-21961-00-00 | . Patch 1 | 1 |
| 1 | 8GL-21962-00-00 | . Patch 2 | 1 |
| 1 | 8GL-21965-00-00 | . Patch 5 | 1 |
| 1 | 8GL-21966-00-00 | . Patch 6 | 1 |
| 1 | 8GL-21295-00-00 | . ..Nut | 1 |
| 1 | 8GL-2131D-00-00 | . .Plate, Cover | 1 |
| 57 | 90267-48010-00 | . Rivet, Blind (4.8X12 Yellow) | 57 |
| 1 | 90462-08061-00 | . .Clamp | 1 |
| 1 | 90462-08064-00 | . .Clamp | 1 |
| 14 | 90267-48016-00 | . Rivet, Blind (4.8X16.4 Yellow | 14 |
| 1 | 8GL-21960-00-00 | Footrest Comp. 1 | 1 |
| 1 | 8GL-21970-00-00 | Footrest Comp. 2 | 1 |
| 2 | 95827-10030-00 | Bolt, Flange | 2 |
| 1 | 8GL-21920-00-00 | Housing, Reinf Sub-Assy (L.H) | 1 |
| 2 | 95812-08020-00 | Bolt, Flange | 2 |
| 1 | 8GL-21916-00-00 | Panel, Sub Frame 5 | 1 |
| 10 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 10 |
| 1 | 8GL-2194L-00-00 | . .Stay, Muffer | 1 |
| 2 | 8GL-21946-00-00 | . .Bracket, Seat Fitting | 2 |
| 8 | 90176-06055-00 | Nut, Crown | 8 |
| 2 | 8GL-22151-00-00 | Seal, Guard | 2 |
| 2 | 8GL-22152-00-00 | Seal, Guard | 2 |
| 2 | 8GL-21967-00-00 | Patch 7 | 2 |
| 1 | 8GL-21988-00-00 | Patch 8 | 1 |
| 2 | 8GL-21978-00-00 | Protector, Frame | 2 |
| 1 | 8GL-2196M-00-00 | Bracket, 5 | 1 |
| 1 | 8GL-2197M-00-00 | Bracket, 6 | 1 |
| 2 | 8GL-21443-00-00 | Bracket, Protector Rear | 2 |
| 1 | 8GL-27471-00-00 | Bar, Footrest 1 | 1 |
| 1 | 8GL-27472-00-00 | Bar, Footrest 2 | 1 |
| 4 | 92012-06014-00 | Bolt, Button Head | 4 |
| 95822-06012-00 | Bolt, Flange | ||
| 1 | 8GL-21151-00-00 | Bracket, Rear Fender 1 | 1 |
| 1 | 8GL-21152-00-00 | Bracket, Rear Fender 2 | 1 |
| 2 | 180-22117-00-00 | Cap | 2 |
| 74 | 90267-47195-00 | Rivet, Blind (4.7X16.4 Yellow) | 74 |
| 1 | 8GL-21852-00-00 | Damper | 1 |
| 1 | 8GL-2179D-00-00 | Plate, Epa Offroad 2 | 1 |
| 2 | 8GL-2199A-00-00 | Graphic 1 UR FOR DPBSE | 2 |
| 2 | 8GL-2199A-20-00 | Graphic 1 UR FOR BWS1 | 2 |
