Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 4 |
| 2 | 207584034 | Hex. Flange Screw, Scotch Grip | 2 |
| 1 | 210261680 | Hex. Flange Screw M6 X 16 | 1 |
| 2 | 232361600 | Nut M6 | 2 |
| 1 | 232561494 | Elastic Stop Nut M6 | 1 |
| 4 | 233251494 | Elastic Flange Nut M5 Model-Australia | 4 |
| 6 | 233261494 | Hex. Flange Elastic Nut M6 | 6 |
| 2 | 234041480 | Flat Washer 4 mm Model-Australia | 2 |
| 2 | 234051670 | Flat Washer M5 Model-Australia | 2 |
| 2 | 234052670 | Stainless Steel Flat Washer M5 | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 2 | 250000303 | Torx Truss Screw M6 X 20 | 2 |
| 1 | 250000348 | Torx Truss Screw M6 X 16 | 1 |
| 2 | 250000350 | Torx Truss Screw M6 X 20 | 2 |
| 1 | 250000454 | Torx Screw M6 X 12 | 1 |
| 2 | 250000575 | Torx-Truss M4 X 16 Model-Australia | 2 |
| 1 | 250000577 | Torx Truss Screw K40 X 12 | 1 |
| 2 | 250000630 | Torx Truss Screw M6 X 25 Model-Australia | 2 |
| 2 | 250000652 | Socket Screw M5 X .80 X 16 Model-Australia | 2 |
| 1 | 250000724 | Torx Screw M5 X 20 | 1 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 | 1 |
| 1 | 250100176 | Panel Nut M5 X 0.8 | 1 |
| 2 | 250200024 | Rubber Washer 5 mm Model-Australia | 2 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 293740028 | Dual Lock Velcro Washer 3/4" | 1 |
| 2 | 293750008 | Tie Wrap 368 mm | 2 |
| 1 | 414745900 | Tuflock Phillips Plastic Screw | 1 |
| 1 | 517302785 | Edge Clip | 1 |
| 1 | 518325518 | RH Upper Side Panel Foam | 1 |
| 1 | 518327010 | LH ROCKER PANEL FOAM | 1 |
| 1 | 518327011 | RH ROCKER PANEL FOAM | 1 |
| 518327438 | RH LATERAL PANEL FOAM | ||
| 1 | 518327441 | Lateral Console Foam | 1 |
| 2 | 518327579 | LATERAL CONSOLE FOAM | 2 |
| 1 | 518327600 | LH UPPER PANEL FOAM | 1 |
| 1 | 705001542 | LH REAR GRILL | 1 |
| 1 | 705001544 | RH REAR GRILL | 1 |
| 705001572 | RED REAR LATERAL REFLECTOR Model-North America | ||
| 705004657 | Steel Black Rear Tip Model-Steel Black Met | ||
| 1 | 705002092 | Lower Belt Guard | 1 |
| 705002367 | LICENCE PLATE SUPPORT | ||
| 1 | 705002369 | LH LATERAL GRILL | 1 |
| 1 | 705002508 | LH Heat Reflective Sheet | 1 |
| 705002509 | BLACK RH REAR PANEL FOAM | ||
| 3 | 705002649 | Quarter Turn Screw | 3 |
| 6 | 705002650 | Washer | 6 |
| 3 | 705002651 | Quarter Turn Nut | 3 |
| 1 | 705002980 | LH REINFORCEMENT PLATE | 1 |
| 1 | 705002981 | RH Reinforcement Plate | 1 |
| 1 | 705003207 | Plastic Washer | 1 |
| 705004666 | FENDER REAR B-266 Model-Steel Black Met Australia | ||
| 705004666 | FENDER REAR B-266 Model-Steel Black Met Europe | ||
| 1 | 705004660 | Steel Black Rear Fender Model-Steel Black Met North America | 1 |
| 705004636 | LH RADIATOR MOULDING | ||
| 705005262 | LH RADIATOR GRILL | ||
| 705005263 | RH RADIATOR GRILL | ||
| 1 | 705005394 | LH SERVICE CENTER | 1 |
| 1 | 705005409 | LH Tank Cover | 1 |
| 1 | 705005410 | RH TANK COVER | 1 |
| 1 | 705005413 | LH DEFLECTOR PANNEL | 1 |
| 1 | 705005462 | HEAT DEFLECTOR | 1 |
| 1 | 705005739 | LATERAL CONSOLE SUPPORT | 1 |
| 1 | 705005774 | RH SERVICE CENTER | 1 |
| 705005261 | RH RADIATOR MOULDING | ||
| 1 | 705006070 | RH REAR FENDER REINFORCEMENT | 1 |
| 705006085 | RH REAR FENDER SUPPORT | ||
| 1 | 705006086 | Rear Fender Support | 1 |
| 1 | 705006136 | LH REAR FENDER REINFORCEMENT | 1 |
| 1 | 705006256 | PANEL_BODY UP R B-266 Model- Steel Black Met | 1 |
| 1 | 705006251 | Black LH Side Panel Model-Steel Black Met | 1 |
| 1 | 705006242 | Black RH Side Panel Model-Steel Black Met | 1 |
| 1 | 705006531 | UPPER HEAT SEAL | 1 |
| 1 | 705006532 | LOWER HEAT SEAT | 1 |
| 1 | 219704364 | Neoprene Seal (1PAC=3M) | 1 |
| 1 | 705005267 | RH Rocker Panel | 1 |
| 1 | 705006829 | UNDER TAIL COVER | 1 |
| 1 | 705006981 | LH INNER HEAT DEFLECTOR | 1 |
| 1 | 705005266 | LH ROCKER PANEL | 1 |
| 705007018 | BACKUP LIGHT BRACKET Model-Australia | ||
| 1 | 705007029 | HEAT SHIELD | 1 |
| 1 | 705007053 | Heat Shield Rocker Panel | 1 |
| 1 | 705007158 | BACKUP LIGHT SUPPORT ASS'Y Model-Australia | 1 |
| 1 | 705007213 | UPPER BELT GUARD | 1 |
| 1 | 705007743 | STEEL BLACK LH UPPER SIDE PANEL Model-Steel Black Met North America, Europe, Australia | 1 |
| 1 | 705007744 | STEEL BLACK RH UPPER SIDE PANEL Model-Steel Black Met North America, Europe, Australia | 1 |
| 1 | 705007329 | LH UPPER SIDE PANEL Model-North America, Europe, Australia | 1 |
| 1 | 705007330 | RH UPPER SIDE PANEL Model-North America, Europe, Australia | 1 |
| 705004971 | CENTER PANNEL Model-ST STD, S | ||
| 1 | 705007668 | Steel Black RH Side Console Model ST STD Steel Black Met | 1 |
| 1 | 705007665 | Steel Black LH Side Console Model-ST STD Steel Black Met | 1 |
| 1 | 705008908 | PANEL_BODY REAR L B-266 Model-Steel Black Met | 1 |
| 1 | 705008909 | PANEL_BODY REAR R B-266 Model-Steel Black Met | 1 |
| 1 | 705009315 | Passenger Handle | 1 |
| 1 | 705009351 | DEFLECTOR_BODY PANEL RH | 1 |
| 1 | 708000759 | Rubber Stopper | 1 |
| 1 | 710003349 | License Plate Light Model-Australia | 1 |
| 1 | 710003319 | REVERSE LIGHT Model-Australia | 1 |
| 710003435 | 21W Bulb Model-Australia | ||
| 1 | 705005447 | LH Skid Plate | 1 |
