Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 207065544 | Hex. Screw M6 X 55 | 4 |
| 2 | 207663544 | Hex. Flange Screw M6 X 35 | 2 |
| 4 | 207682534 | Hex. Flange Screw M8 X 25 Model-Australie, Brezil, Europe | 4 |
| 1 | 210262080 | Hex. Forming Screw M6 X 20 | 1 |
| 230060060 | Hex. Screw M6 X 100 | ||
| 1 | 230065060 | Hex. Screw M6 X 150 | 1 |
| 2 | 232180600 | Hex. Jam Nut M8 | 2 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 6 | 250000081 | Torx Screw M6 X 25 | 6 |
| 1 | 250000350 | Torx Truss Screw M6 X 20 | 1 |
| 4 | 250000446 | Torx Screw M6 X 20, Scotch Grip | 4 |
| 1 | 250000454 | Torx Screw M6 X 12 | 1 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 Model-ST | 2 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 | 1 |
| 4 | 269500706 | Sleeve | 4 |
| 1 | 269501481 | REAR ARM | 1 |
| 1 | 269501482 | FRONT ARM | 1 |
| 1 | 269501943 | Elastic Nut Housing M8 | 1 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
| 1 | 219704371 | Neoprene Seal 3000 mm Long | 1 |
| 1 | 293740028 | Dual Lock Velcro Washer 3/4" | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 293830143 | Rubber Pad Model-North America, Europe, Australie, Japon | 1 |
| 2 | 414436900 | BLACK SNAP CAP | 2 |
| 12 | 414479100 | Clip | 12 |
| 1 | 517305459 | HOOD CABLE | 1 |
| 1 | 518325515 | LH FRONT PANEL FOAM | 1 |
| 1 | 518325516 | RH FRONT PANEL FOAM | 1 |
| 1 | 705001469 | LH HEADLAMP BEZEL Model-Australie, Brezil, Europe | 1 |
| 1 | 705001470 | RH Headlamp Bezel Model-Australie, Brezil, Europe | 1 |
| 1 | 705001541 | LH Air Duct Model-North America | 1 |
| 1 | 705001543 | RH Air Duct Model-North America | 1 |
| 1 | 705002223 | Lug | 1 |
| 1 | 705007379 | Latch | 1 |
| 1 | 705004796 | BLACK LH HEADLAMP SUPPORT Model-Australie, Brezil, Europe | 1 |
| 1 | 705004797 | BLACK RH HEADLAMP SUPPORT Model-Australie, Brezil, Europe | 1 |
| 1 | 705002837 | Skid Plate | 1 |
| 1 | 705003207 | Plastic Washer | 1 |
| 1 | 705006611 | TRIM_HOOD F B-349 Model-Circuit Yellow Met. | 1 |
| 705007681 | COGNAC FRONT FASCIA Model-Cognac | ||
| 1 | 705004572 | Steel Black Front Fascia Model-Steel Black Met. | 1 |
| 1 | 705003875 | Pearl White Front Fascia Model-Vegas White Pearl | 1 |
| 1 | 705003911 | Spring | 1 |
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long | 1 |
| 1 | 705004628 | Battery Cover Ass'Y | 1 |
| 1 | 705008060 | COGNAC LH FRONT PANNEL Model-Cognac Brezil | 1 |
| 1 | 705007323 | BLACK LH FRONT PANNEL Model-Steel Black Met. Brezil | 1 |
| 1 | 705008059 | COGNAC RH FRONT PANNEL Model-Cognac Brezil | 1 |
| 1 | 705007324 | Black RH Front Pannel Model-Steel Black Met. Brezil | 1 |
| 1 | 705006604 | Yellow Bumper Cover Model-Circuit Yellow Met. | 1 |
| 705007671 | PANEL_BODY LWR F B-367 Model-Cognac | ||
| 1 | 705007666 | STEEL BLACK BUMPER COVER Model-ST S Steel Black Met. | 1 |
| 1 | 705006873 | Vegas White Bumper Cover Model-ST S Vegas White Pearl | 1 |
| 1 | 705007673 | Vegas White Bumper Cover Model-Vegas White Satin | 1 |
| 1 | 705007991 | CIRCUIT YELLOW HOOD Model-Circuit Yellow Met. | 1 |
| 705007675 | COGNAC HOOD Model-Cognac | ||
| 1 | 705007992 | Steel Black Hood Model-Steel Black Met. | 1 |
| 1 | 705007988 | Vegas White Pearl, Hood Model-Vegas White Pearl | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 705008320 | Storage Bin Ass'y | 1 |
| 2 | 705007483 | Fuse Cover Ass'y | 2 |
| 1 | 705007691 | CIRCUIT YELLOW LH FRONT PANNEL Model-Circuit Yellow Met. | 1 |
| 1 | 705007698 | PANEL_BODY FL B-367 Model-Cognac Australie | 1 |
| 1 | 705007698 | PANEL_BODY FL B-367 Model-Cognac Europe | 1 |
| 1 | 705007698 | PANEL_BODY FL B-367 Model-Cognac North America | 1 |
| 1 | 705007696 | STEEL BLACK LH FRONT PANNEL Model-Steel Black Met. Australie | 1 |
| 1 | 705007696 | STEEL BLACK LH FRONT PANNEL Model-Steel Black Met. Europe | 1 |
| 1 | 705007696 | STEEL BLACK LH FRONT PANNEL Model-Steel Black Met. North America | 1 |
| 1 | 705007695 | VEGAS WHITE PEARL LH FRONT PANNEL Model-Vegas White Pearl | 1 |
| 1 | 705007700 | VEGAS WHITE LH FRONT PANNEL Model-Vegas White Satin | 1 |
| 1 | 705007702 | CIRCUIT YELLOW RH FRONT PANNEL Model-Circuit Yellow Met. | 1 |
| 1 | 705007709 | PANEL_BODY FR B-367 Model-Cognac Australie | 1 |
| 1 | 705007709 | PANEL_BODY FR B-367 Model-Cognac Europe | 1 |
| 1 | 705007709 | PANEL_BODY FR B-367 Model-Cognac North America | 1 |
| 1 | 705007707 | Steel Black RH Front Pannel Model-Steel Black Met. Australie | 1 |
| 1 | 705007707 | Steel Black RH Front Pannel Model-Steel Black Met. Europe | 1 |
| 1 | 705007707 | Steel Black RH Front Pannel Model-Steel Black Met. North America | 1 |
| 1 | 705007706 | VEGAS WHITE PEARL RH FRONT PANNEL Model-Vegas White Pearl | 1 |
| 1 | 705007711 | VEGAS WHITE RH FRONT PANNEL Model-Vegas White Satin | 1 |
