Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 to 34a | ||
| 1 | 417222966 | Fixed Flange Ass'y | 1 |
| 1 | 417223065 | Sliding Flange Ass'y Includes 3 to 6 | 1 |
| 1 | 417223086 | Bushing | 1 |
| 293800118 | ADHESIVE LOCTITE 680 | ||
| 1 | 293370037 | Circlip | 1 |
| 3 | 417222671 | Lever | 3 |
| 3 | 417222947 | Roller | 3 |
| 6 | 417004302 | Stopper Washer | 6 |
| 3 | 417223177 | Dowel Pin Ass'y Includes 10 to 12 | 3 |
| 1 | 417222595 | Threaded Pin, M6 | 1 |
| 1 | 250000407 | SOCKET SET SCREW M6 X 12 | 1 |
| 3 | 732958001 | Cotter Pin | 3 |
| 3 | 417223164 | Lever Axle | 3 |
| 1 | 417222312 | Spring Seat | 1 |
| 1 | 414762800 | Spring, Green/violet | 1 |
| 1 | 417222759 | Spring Cover Ass'y Includes 17 to 19 | 1 |
| 1 | 417009204 | Bushing | 1 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 3 | 205084044 | Socket Head Screw M8 X 1.25 X 40 | 3 |
| 3 | 250200009 | Lock Washer 8 mm | 3 |
| 417223200 | GOVERNOR CUP ASS'Y | ||
| 3 | 417223098 | Ramp 441 | 3 |
| 3 | 250400050 | Spring Pin M10 X 22 | 3 |
| 6 | 250000418 | Hex. Flange Screw M6 X 18, Scotch Grip | 6 |
| 3 | 417223197 | CALIBRATION SCREW | 3 |
| 3 | 417005600 | Washer | 3 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 6 | 732401030 | O-Ring | 6 |
| 420460045 | Corrugated Tube NW 6 Slit 385MM | ||
| XXX | Not Available As Spare Parts | ||
| 1 | 417009205 | Guard | 1 |
| 6 | 250000416 | Serrated Hex. Flange Bolt M6 | 6 |
| 417222826 | BUSHING | ||
| 1 | 250200006 | Spring Washer 14 mm | 1 |
| 1 | 417300394 | Drive Bolt Pulley | 1 |
| 1 | 516003708 | DECAL, NOTICE, DRIVE PULLEY BOLT | 1 |
| 1 | 516004045 | DECAL RPM, MAXIMUM HORSEPOWER | 1 |
| 1 | 417127174 | Fixe Flange Ass'y Includes 39 to 43 | 1 |
| 2 | 417127016 | Pulley Roller | 2 |
| 2 | 417127128 | Stud | 2 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| 2 | 414753500 | Circlip | 2 |
| 1 | 417126955 | Sliding Flange Ass'y Includes 44 to 44a | 1 |
| 1 | 293370049 | Circlip | 1 |
| 1 | 417127133 | Cam Ass'y Includes 45 to 45a | 1 |
| 1 | 417127062 | Violet Spring | 1 |
| 2 | 417127116 | Swivel Abutment | 2 |
| 4 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 4 |
| 1 | 417127173 | Pulley Adjuster Ass'y | 1 |
| 1 | 208652044 | Phillips Screw M5 X 20 | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 232551414 | Elastic Stop Nut M5 | 1 |
| 1 | 417127155 | Washer | 1 |
| 1 | 504152574 | Ball Bearing | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 417300377 | Belt | 1 |
| 1 | 417300357 | Belt Guard | 1 |
| 1 | 516002670 | WARNING DECAL, SECURITY BELT GUARD | 1 |
| 1 | 417300380 | Reinforcement | 1 |
| 3 | 390909200 | Avex Rivet | 3 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300356 | Side Protector | 1 |
| 5 | 293150103 | Pop Rivet 3/16" | 5 |
| 1 | 417300360 | FRONT BELT GUARD BRACKET | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 417300375 | Belt Guard Bracket | 1 |
| 4 | 250000145 | Torx Screw M5 X 14 | 4 |
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 861805577 | QRS XD Roller Kit (2) | 1 |
