Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | B5Y-24129-00-P0 | COVER, SIDE 1 UR FOR MDNM6 | 1 |
| 1 | B5Y-24129-00-3E | COVER, SIDE 1 UR FOR PGD | 0 |
| 2 | 90387-05035-00 | COLLAR | 1 |
| 3 | 98902-05008-00 | SCREW, BIND | 1 |
| 4 | 90183-05076-00 | NUT, SPRING | 1 |
| 5 | 90338-06018-00 | PLUG | 1 |
| 6 | 90110-05014-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 7 | 97702-50012-00 | SCREW, TAPPING | 3 |
| 8 | 4C8-21746-00-00 | DAMPER | 1 |
| 9 | 5YU-2177N-00-00 | DAMPER, LOCATING 4 | 1 |
| 10 | B5Y-28345-00-00 | MOLE 1 | 1 |
| 11 | 90183-05042-00 | NUT, SPRING | 1 |
| 12 | B5Y-2137W-00-P0 | SCOOP, AIR 1 UR FOR MDNM6 | 1 |
| 12 | B5Y-2137W-00-33 | SCOOP, AIR 1 UR YB FOR PGD | 0 |
| 13 | 90111-05062-00 | BOLT,HEX. SOCKET BUTTON | 3 |
| 14 | 90202-05180-00 | WASHER, PLATE | 3 |
| 15 | 1RC-2413B-01-00 | EMBLEM | 1 |
| 16 | B5Y-2172E-00-P0 | STAY, SIDE COVER 1 UR FOR MDNM6 | 1 |
| 16 | B5Y-2172E-00-33 | STAY, SIDE COVER 1 UR YB FOR PGD | 0 |
| 17 | 90183-05042-00 | NUT, SPRING | 2 |
| 18 | 90183-05076-00 | NUT, SPRING | 2 |
| 19 | 90480-14003-00 | GROMMET | 3 |
| 20 | 90387-06260-00 | COLLAR | 3 |
| 21 | 90105-06203-00 | BOLT, FLANGE | 3 |
| 22 | B5Y-27475-00-P0 | CAP 1 UR FOR MDNM6 | 1 |
| 22 | B5Y-27475-00-33 | CAP 1 UR YB FOR PGD | 0 |
| 23 | 90183-05M02-00 | NUT, SPRING | 2 |
| 24 | B5Y-2837N-00-00 | GRILL, AIR INTAKE 1 | 1 |
| 25 | 90269-05039-00 | RIVET | 2 |
| 26 | B5Y-24139-00-P0 | COVER, SIDE 2 UR FOR MDNM6 | 1 |
| 26 | B5Y-24139-00-3E | COVER, SIDE 2 UR FOR PGD | 0 |
| 27 | 90387-05035-00 | COLLAR | 1 |
| 28 | 98902-05008-00 | SCREW, BIND | 1 |
| 29 | 90183-05076-00 | NUT, SPRING | 1 |
| 30 | 90338-06018-00 | PLUG | 1 |
| 31 | 90110-05014-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 32 | 97702-50012-00 | SCREW, TAPPING | 3 |
| 33 | 4C8-21746-00-00 | DAMPER | 1 |
| 34 | 5YU-2177N-00-00 | DAMPER, LOCATING 4 | 1 |
| 35 | B5Y-28346-00-00 | MOLE 2 | 1 |
| 36 | 90183-05042-00 | NUT, SPRING | 1 |
| 37 | B5Y-2137X-00-P0 | SCOOP, AIR 2 UR FOR MDNM6 | 1 |
| 37 | B5Y-2137X-00-33 | SCOOP, AIR 2 UR YB FOR PGD | 0 |
| 38 | 90111-05062-00 | BOLT,HEX. SOCKET BUTTON | 3 |
| 39 | 90202-05180-00 | WASHER, PLATE | 3 |
| 40 | 1RC-2413B-01-00 | EMBLEM | 1 |
| 41 | B5Y-2174E-00-P0 | STAY, SIDE COVER 2 UR FOR MDNM6 | 1 |
| 41 | B5Y-2174E-00-33 | STAY, SIDE COVER 2 UR YB FOR PGD | 0 |
| 42 | 90183-06069-00 | NUT, SPRING | 3 |
| 43 | 90183-05042-00 | NUT, SPRING | 2 |
| 44 | 90183-05076-00 | NUT, SPRING | 2 |
| 45 | B5Y-27476-00-P0 | CAP 2 UR FOR MDNM6 | 1 |
| 45 | B5Y-27476-00-33 | CAP 2 UR YB FOR PGD | 0 |
| 46 | 90183-05M02-00 | NUT, SPRING | 2 |
| 47 | B5Y-2837N-00-00 | GRILL, AIR INTAKE 1 | 1 |
| 48 | 90269-05039-00 | RIVET | 2 |
| 49 | B5Y-241B1-00-P0 | COVER, TANK UR FOR MDNM6 | 1 |
| 49 | B5Y-241B1-00-3E | COVER, TANK UR FOR PGD | 0 |
| 50 | 90269-06019-00 | RIVET | 2 |
| 51 | 4B5-2174X-00-00 | DAMPER | 1 |
| 52 | B5Y-2137U-00-00 | GUIDE, AIR 1 | 1 |
| 53 | B5Y-2837V-00-00 | GRILL, AIR OUTLET 1 | 1 |
| 54 | 90183-05M02-00 | NUT, SPRING | 3 |
| 55 | B5Y-2137V-00-00 | GUIDE, AIR 2 | 1 |
| 56 | B5Y-2837W-00-00 | GRILL, AIR OUTLET 2 | 1 |
| 57 | 90183-05M02-00 | NUT, SPRING | 3 |
| 58 | B5Y-2172K-00-00 | BRACKET 1 | 1 |
| 59 | 90183-06069-00 | NUT, SPRING | 5 |
| 60 | 663-45119-01-00 | CAP, GREASE NIPPLE | 1 |
| 61 | 95702-06500-00 | NUT, WITH WASHER | 1 |
| 62 | 95D37-06020-00 | BOLT, FLANGE DEEP | 1 |
| 63 | 90480-01022-00 | GROMMET | 1 |
| 64 | B5Y-2172L-00-00 | BRACKET 2 | 1 |
| 65 | 90480-14003-00 | GROMMET | 3 |
| 66 | 90387-06260-00 | COLLAR | 3 |
| 67 | 90105-06203-00 | BOLT, FLANGE | 3 |
| 68 | 90338-06018-00 | PLUG | 1 |
| 69 | 95D37-06020-00 | BOLT, FLANGE DEEP | 1 |
| 70 | B5Y-24738-00-00 | BRACKET, SEAT | 1 |
| 71 | 97702-50012-00 | SCREW, TAPPING | 1 |
| 72 | B5Y-2173E-20-00 | GRAPHIC 1 UR FOR MDNM6 | 1 |
| 72 | B5Y-2173E-10-00 | GRAPHIC 1 UR FOR PGD | 0 |
| 73 | B5Y-2173F-20-00 | GRAPHIC 2 UR FOR MDNM6 | 1 |
| 73 | B5Y-2173F-10-00 | GRAPHIC 2 UR FOR PGD | 0 |
