Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 205444086 | Socket Head Screw M4 X 40 | 2 |
| 2 | 207144044 | Hex. Cap Screw | 2 |
| 1 | 207144060 | Hex. Screw M4 X 40 | 1 |
| 1 | 207562044 | Flange Screw M6 X 20, Scotch Grip | 1 |
| 3 | 207662084 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 207662584 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 207682034 | Hex. Flange Screw | 1 |
| 1 | 210261080 | Hex. Flange Screw M6 X 10 | 1 |
| 1 | 210261280 | Hex. Flange Screw M6 X 12 | 1 |
| 2 | 210261680 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 232541414 | Elastic Stop Nut M4 | 2 |
| 1 | 232541484 | Elastic Stop Nut M4 | 1 |
| 1 | 232561434 | Elastic Stop Nut M6 | 1 |
| 2 | 233251494 | Elastic Flange Nut M5 | 2 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 2 | 234041480 | Flat Washer 4 mm | 2 |
| 1 | 234041600 | Flat Washer 4 mm, Stainless | 1 |
| 9 | 234052670 | Stainless Steel Flat Washer M5 | 9 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 2 | 250000242 | Truss Torx Screw M4 X 16 | 2 |
| 10 | 250000287 | Flange Torx Screw K40 X 16 Japan | 10 |
| 2 | 250000446 | Torx Screw M6 X 20, Scotch Grip | 2 |
| 9 | 250000715 | Torx Truss Screw M5 X 20 | 9 |
| 1 | 250000721 | Torx Truss Screw M6 X 16 | 1 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 | 1 |
| 1 | 250100143 | Extruded Panel Nut M4 X 0.7 | 1 |
| 2 | 250100169 | Panel Nut M6 X 1 | 2 |
| 9 | 250100176 | Panel Nut M5 X 0.8 | 9 |
| 1 | 270000141 | Clip | 1 |
| 1 | 278003071 | Control Gear Motor | 1 |
| 1 | 293150150 | Pop Rivet | 1 |
| 1 | 293370013 | E-Circlip | 1 |
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 1 | 293750063 | Clip Tie-Rap | 1 |
| 1 | 390403000 | Pop Rivet 5/32 | 1 |
| 1 | 390402400 | Pop Rivet 3/16" | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 520000528 | Latch | 1 |
| 1 | 707000586 | Foam Filter | 1 |
| 1 | 707000995 | Pressure And Temperature Sensor | 1 |
| 1 | 709401171 | Position Steering Sensor | 1 |
| 1 | 710001346 | Passenger Detection Switch | 1 |
| 1 | 710001364 | Starter Relay | 1 |
| 2 | 710001379 | Brake Pressure Switch Ass'y | 2 |
| 2 | 710002168 | Packard Connector With Plug | 2 |
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 219800305 | BATTERY YUASA YTX24HL Brazil | ||
| 1 | 410922962 | Battery YUASA YTX24-HL Except Brazil | 1 |
| 1 | 219800333 | VCM Module | 1 |
| 1 | 710002677 | Yaw Rate Sensor | 1 |
| 1 | 710004214 | PBM MODULE | 1 |
| 1 | 710002889 | Reverse Cable | 1 |
| 1 | 710002893 | Battery Holder | 1 |
| 1 | 710002899 | Clip Tie-Rap | 1 |
| 1 | 710002945 | Battery Guard | 1 |
| 1 | 710003279 | Shock Damper | 1 |
| 1 | 710003348 | License Plate Light North America | 1 |
| 1 | 415129261 | Bulb 12V 10W | 1 |
| 1 | 710003349 | License Plate Light Except North America | 1 |
| 1 | 710003412 | Brake Light Switch Ass'y | 1 |
| 1 | 710003685 | LH Headlamp | 1 |
| 1 | 710003686 | RH HEADLAMP | 1 |
| 2 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 2 |
| 2 | 219800280 | Rubber Cap Protector | 2 |
| 2 | 219800281 | Spring | 2 |
| 1 | 710003704 | WIRING HARNESS North America | 1 |
| 1 | 710004987 | Dashboard Harness Except North America | 1 |
| 1 | 710003707 | LH Rear Flasher Except Japan | 1 |
| 1 | 710004396 | Tail Light LH Japan | 1 |
| 1 | 710003708 | RH Rear Flasher Except Japan | 1 |
| 1 | 710004397 | Tail Light RH Japan | 1 |
| 1 | 219800304 | Flasher Bulb Except Japan | 1 |
| 1 | 710003776 | Actuator | 1 |
| 1 | 710003879 | Reverse Light | 1 |
| 1 | 219800322 | Bulb 12V 10W | 1 |
| 1 | 710003951 | Speedometer | 1 |
| 1 | 415129349 | Lens | 1 |
| 1 | 710003984 | WIRING HARNESS REAR North America | 1 |
| 710003985 | CARGO HARNESS Europe, Australia, Brazil | ||
| 710004909 | -Cargo Harness Japan | ||
| 710005121 | TAIL-STOP-FLASHER-LIGHTS ADAPTER Japan | ||
| 1 | 710003996 | VCM Harness Protector | 1 |
| 2 | 710004056 | Rear Light Japan | 2 |
| 2 | 710004057 | Rear Flasher Japan | 2 |
| 2 | 715900043 | Bulb 12V 21W | 2 |
| 710004093 | Reverse Actuator Support | ||
| 1 | 710004105 | Flasher Module North America | 1 |
| 1 | 710004150 | LH Low Beam Europe, Brazil | 1 |
| 1 | 710004152 | LH Low Beam Australia, Japan | 1 |
| 1 | 710004151 | RH Low Beam Europe, Brazil | 1 |
| 1 | 710004153 | RH Low Beam Australia, Japan | 1 |
| 1 | 710004229 | HORN | 1 |
| 710004412 | BLACK HORN SUPPORT | ||
| 2 | 710004400 | Rear Flasher Europe, Australia, Brazil | 2 |
| 1 | 710004815 | Plate | 1 |
