Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 7512018 | SCREW(10) | 2 |
| 1 | 4060122 | AC REGULATOR KIT | 1 |
| 5210650 | HEAT SINK | ||
| 2 | 5410374 | SEAL, O RING, | 2 |
| 5431211-070 | LOUVER, INTAKE | ||
| 5810458 | FOAM, INTAKE (Lite, Deluxe) | ||
| 7073124 | DECAL,FUEL SHUT-OFF(LITE) | ||
| 4110038 | IGNITION SWITCH (Lite, StarLite) | ||
| 4110061 | Discontinued (Deluxe) | ||
| 7080405 | CABLE, CHOKE(LITE) (Lite, Deluxe) | ||
| 7080411 | Discontinued (StarLite) | ||
| 1 | 2200188 | CHOKE CONTROL KIT | 1 |
| 5431157-070 | CONSOLE (Lite, StarLite) | ||
| 1 | 5431636 | CONSOLE,BLACK,DELUXE (Deluxe) | 1 |
| 4110116 | SWITCH,ROCKER,W/INDIC. (Lite, Deluxe) | ||
| 7542807 | NUT-IGNITION SWITCH | ||
| 2 | 5410378 | IGNITION KEY | 2 |
| 4040012 | INDICATOR'LOW-OIL'WARN. (Deluxe) | ||
| 4040014 | Discontinued (Deluxe) | ||
| 1 | 7080229 | NUT-CHOKE SLIDE | 1 |
| 1 | 7571610 | WASHER-LOCK | 1 |
| 4 | 7512253 | SCREW | 4 |
| 4 | 7555776 | FLAT WASHER | 4 |
| 6 | 7621336 | RIVET-5/32(.126-.250)-AL-B(10) (Lite, Deluxe) | 6 |
| 6 | 7555727 | WASHER (10) (Lite, Deluxe) | 6 |
| 5431214-070 | CONSOLE, INNER (Lite, Deluxe) | ||
| 5410425 | STRAP,TOOL COMPARTMENT (Lite) | ||
| 7080311 | Discontinued | ||
| 1 | 5230124 | GUARD-CLUTCH | 1 |
| 7072871 | DECAL,ENG/CLUTCH | ||
| 2 | 7621601 | RIVET AND RETAINER ASSEMBLY | 2 |
| 5410573 | STRAP, HOOD | ||
| 36 | 7621472 | RIVET | 36 |
| 2670071 | REFLECTOR AMBER | ||
| 1 | 5410582 | CATCH HOLE PLUG | 1 |
| 5431155-070 | NOSEPAN,LH,BLK. | ||
| 5211249-067 | PLATE,CLUTCHGUARD,BLK. | ||
| 7621449 | Discontinued | ||
| 1 | 5222332-067 | SUPPORT,CLUTCH GD,BLK. | 1 |
| 5224440 | Discontinued (Lite) | ||
| 5224448 | PIN, (STAR) (StarLite) | ||
| 6 | 7555806 | FLAT WASHER | 6 |
| 7542456 | NUT LOCK | ||
| 5222339-067 | BRKT,LH PANBRACE,BLK. | ||
| 5222340-067 | Discontinued | ||
| 1 | 4020139 | ROSEBUD CLIP | 1 |
| 2 | 7542103 | FLEXLOC NUT | 2 |
| 2 | 7542124 | NYLOK NUT | 2 |
| 5222356-067 | BRKT,SUPPORT,BLK. | ||
| 5810476 | TAPE, FOIL | ||
| 5222345-067 | BRKT,LH BUMP.BRACE,BLK. | ||
| 5222346-067 | BRKT,RH BUMP.BRACE,BLK. | ||
| 2 | 7512297 | SCREW | 2 |
| 20 | 7621467 | RIVET | 20 |
| 2635010-067 | HINGE,LOWER,BLK. | ||
| 6 | 7670040 | U TYPE CLIP | 6 |
| 5810509 | TAPE, FOIL (Lite, Deluxe) | ||
| 5431154-070 | NOSEPAN, CTR. (Lite) | ||
| 5431256 | NOSEPAN,CTR,(STARLITE) (StarLite) | ||
| 5211267-067 | Discontinued | ||
| 8 | 7621418 | RIVET(50) | 8 |
| 5810475 | TAPE, FOIL (Lite, Deluxe) | ||
| 5810477 | TAPE, FOIL | ||
| 5431156-070 | NOSEPAN,RH,BLK. | ||
| 18 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 18 |
| 5431252 | COVER, LH SHOCK | ||
| 5431253 | Discontinued | ||
| 18 | 7621457 | RIVET | 18 |
| 5810482 | TAPE, FOIL,(PAN) | ||
| 2 | 7670067 | DART CLIP (Nylon) | 2 |
| 5810478 | Discontinued | ||
| 5811078 | Discontinued |
