Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518328207 | Frame Includes 1 To 31 | ||
| 518328188 | MODULE E Includes 2 To 11 | ||
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 1 | 518326198 | Front Member | 1 |
| 4 | 605636002 | Clinch Nut Hexsert M8 | 4 |
| 7 | 390909100 | Avex Rivet | 7 |
| 2 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 4 | 293150119 | Hemlock Rivet, 6.5 mm | 4 |
| 2 | 505072690 | Leg Bushing | 2 |
| 1 | 518327983 | SUPPORT_EXHAUST | 1 |
| 1 | 293150163 | Rivet Hucklok | 1 |
| 1 | 518328317 | Oil Plate | 1 |
| 2 | 250000325 | Torx Truss Screw M6 X 12 | 2 |
| 1 | 509000867 | Tunnel Radiator | 1 |
| 2 | 518326107 | Fastening rail | 2 |
| 518328440 | LH FOOTREST | ||
| 518328441 | RH Footrest | ||
| 1 | 518327884 | Fastening Bracket | 1 |
| XXXX | Not Available As Spare Part - LH Drive Axle Cover | ||
| XXXX | Not Available As Spare Part - RH Drive Axle Cover | ||
| 518327003 | TUNNEL SUPPORT | ||
| 2 | 518327457 | SEAT BOX BRACKET | 2 |
| 1 | 518326109 | SUPPORT TUBE BRACKET LH | 1 |
| 1 | 518326110 | SUPPORT TUBE BRACKET RH | 1 |
| 518328096 | CLINCH NUT PLATE | ||
| 1 | 518325643 | LH Frame Corner | 1 |
| 1 | 518325644 | RH Frame Corner | 1 |
| 2 | 518325560 | Adhesive Patch | 2 |
| 1 | 518325645 | Rear Profile | 1 |
| 6 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 6 |
| 6 | 293150174 | Hemlock Rivet, 6.4 mm | 6 |
| 1 | 390909100 | Avex Rivet | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 293150119 | Hemlock Rivet, 6.5 mm | 1 |
| 1 | 293150183 | Rivet | 1 |
| 518326123 | GEARBOX FRONT PLATE | ||
| 1 | 518326124 | Gearbox Rear Plate | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 2 | 518326357 | RUBBER COVER | 2 |
| 1 | 518327595 | LH Footboard Support Tube | 1 |
| 1 | 518327596 | RH Footboard Support Tube | 1 |
| 8 | 390909100 | Avex Rivet | 8 |
| 2 | 207662056 | Hex. Flange Screw M6 x 20 | 2 |
| 2 | 520000492 | Footrest | 2 |
| 518328567 | LH Toe Hold | ||
| 518328570 | RH Toe Hold | ||
| 2 | 605636003 | Clinch Nut M6 Hexsert | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 4 | 250000721 | Torx Truss Screw M6 X 16 | 4 |
| 1 | 514054828 | SPRING BRACKET | 1 |
| 1 | 518327535 | BRACE ASS'Y Includes 50 To 51 | 1 |
| 2 | 512060295 | Rubber Mount | 2 |
| 1 | 234281474 | Conical Spring Washer M8 | 1 |
| 1 | 518326213 | S Module Includes 53 To 54 | 1 |
| 12 | 390909200 | Avex Rivet | 12 |
| 2 | 210262080 | Hex. Forming Screw M6 X 20 | 2 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 6 | 390909100 | Avex Rivet | 6 |
| 5 | 390909200 | Avex Rivet | 5 |
| 1 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 1 |
| 2 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 2 |
| 1 | 207584044 | Hex. Flange Screw M8 X 40, Scotch Grip | 1 |
| 1 | 518326140 | Engine Support | 1 |
| 4 | 390909100 | Avex Rivet | 4 |
| 2 | 293150119 | Hemlock Rivet, 6.5 mm | 2 |
| 1 | 518327004 | Front Member Ass'y Includes 67 To 69 | 1 |
| 1 | 502007077 | LH Bumper Fastener | 1 |
| 1 | 502007078 | RH Bumper Fastener | 1 |
| 2 | 390909200 | Avex Rivet | 2 |
| 6 | 207662044 | Hex. Flange Screw M6 X 20 | 6 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 2 | 224061201 | Flat Washer | 2 |
| 8 | 207662044 | Hex. Flange Screw M6 X 20 | 8 |
| 8 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 8 |
| 4 | 207662044 | Hex. Flange Screw M6 X 20 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 390909200 | Avex Rivet | 4 |
| 518326103 | UPPER SUPPORT TUBE WELDED | ||
| XXXX | Not Available As Spare Part - Lock Washer | ||
| 2 | 518326848 | Upper Column Support | 2 |
| 1 | 518326355 | Center Column Support | 1 |
| 2 | 207662556 | Hex. Flange Screw M6 X 25 | 2 |
| 1 | 518325560 | Adhesive Patch | 1 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
