Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705014359 | Labrador Blue, LH Rear Door Panel | 1 |
| 1 | 705013366 | Hyper Silver, LH Rear Door | 1 |
| 1 | 705013095 | LH Latch | 1 |
| 1 | 705013859 | LH Latch Cover | 1 |
| 1 | 705011358 | LH Lower Door Cover | 1 |
| 1 | 705014364 | Labrador Blue, RH Rear Door Panel | 1 |
| 1 | 705013367 | Hyper Silver, RH Rear Door | 1 |
| 1 | 705011187 | Door Support Includes 2320 to 2320a | 1 |
| 1 | 250000913 | Weld Pin 8mm X 40mm | 1 |
| 2 | 207582054 | Washer Head Hexa. Screw M8 X 20 | 2 |
| 2 | 234081430 | Flat Washer M8 | 2 |
| 1 | 234081100 | Flat Washer 8 mm, Nylon | 1 |
| 1 | 705013096 | RH Latch | 1 |
| 1 | 293850135 | Belt | 1 |
| 1 | 293150103 | Pop Rivet 3/16" | 1 |
| 1 | 293900104 | Bushing | 1 |
| 1 | 705013860 | RH Latch Cover | 1 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 3 | 250000957 | Extruded Panel Nut M6 | 3 |
| 1 | 250000748 | Torx Screw M6 X 45 | 1 |
| 2 | 250000721 | Torx Truss Screw M6 X 16 | 2 |
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 2 | 224061121 | Flat Washer | 2 |
| 1 | 705011359 | Right Lower Door Cover | 1 |
| 2 | 250000749 | Torx Truss Screw M6 X 50 | 2 |
| 1 | 250000722 | Torx Screw M6 X 20 | 1 |
| 5 | 234062670 | Stainless Steel Flat Washer | 5 |
| 2 | 233261466 | Hex. Flange Elastic Nut M6 | 2 |
| 1 | 250000957 | Extruded Panel Nut M6 | 1 |
| 1 | 705014336 | Labrador Blue, LH Front Door Panel | 1 |
| 1 | 705013358 | Hyper Silver, LH Front Door | 1 |
| 1 | 705013535 | LH Latch Cover | 1 |
| 1 | 705010732 | LH Lower Door Panel | 1 |
| 1 | 705014342 | Labrador Blue, RH Front Door Panel | 1 |
| 1 | 705013359 | Hyper Silver, RH Front Door | 1 |
| 1 | 705011187 | Door Support Includes 2820 to 2820a | 1 |
| 2 | 234081100 | Flat Washer 8 mm, Nylon | 2 |
| 1 | 705013536 | RH Latch Cover | 1 |
| 2 | 250000957 | Extruded Panel Nut M6 | 2 |
| 3 | 250000722 | Torx Screw M6 X 20 | 3 |
| 1 | 293850129 | Door Belt | 1 |
| 1 | 705010733 | RH Lower Door Panel | 1 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 250000807 | Torx Truss Screw M6 X 25 | 2 |
| 1 | 705009513 | LH Central Lateral Panel | 1 |
| 1 | 705009514 | RH Central Lateral Panel | 1 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 2 | 705010872 | Insert | 2 |
| 1 | 705011368 | LH Rear Central Lateral Panel | 1 |
| 1 | 705011369 | RH Rear Central Lateral Panel | 1 |
| 2 | 293150108 | Pop Rivet 3/16” | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 1 | 705010676 | LH Rear Lateral Panel | 1 |
| 1 | 705010677 | Deep Black, RH Rear Lateral Panel | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 2 | 705003841 | Support Plate | 2 |
| 14 | 250000722 | Torx Screw M6 X 20 | 14 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 4 | 705003841 | Support Plate | 4 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 1 | 705015489 | LH Central Cage Trim | 1 |
| 1 | 705014860 | LH Central Cage Trim | 1 |
| 1 | 705015490 | RH Central Cage Trim | 1 |
| 1 | 705014862 | RH Central Cage Trim | 1 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 4 | 250000957 | Extruded Panel Nut M6 | 4 |
| 1 | 705014125 | Labrador BLue, LH Central Latch Trim | 1 |
| 1 | 705014126 | Labrador Blue, RH Central Latch Trim | 1 |
| 1 | 705010872 | Insert | 1 |
