Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 704700169 | Tool Kit Includes 20 to 20c | 1 |
| 1 | 529000085 | Socket Wrench 14/16MM | 1 |
| 1 | 529000088 | Driven Open Tool | 1 |
| 1 | 708200340 | Torx Key T30 | 1 |
| 1 | 529000057 | Adjustment Wrench | 1 |
| 1 | 705011317 | Front Fascia | 1 |
| 6 | 250000721 | Torx Truss Screw M6 X 16 | 6 |
| 4 | 250000957 | Extruded Panel Nut M6 | 4 |
| 2 | 705011222 | Amber Reflector | 2 |
| 2 | 233251494 | Elastic Flange Nut M5 | 2 |
| 2 | 250000748 | Torx Screw M6 X 45 | 2 |
| 1 | 705011318 | Fascia Removable Grid | 1 |
| 2 | 517306478 | Clip | 2 |
| 1 | 705012245 | Grille Logo | 1 |
| 1 | 250000725 | Screw M4 X 16 | 1 |
| 1 | 705011319 | LH Headlamp Structure | 1 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 2 | 250000957 | Extruded Panel Nut M6 | 2 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 705011320 | RH Headlamp Structure | 1 |
| 1 | 705012413 | Yellow, LH Hood Ass'y | 1 |
| 2 | 250000721 | Torx Truss Screw M6 X 16 | 2 |
| 2 | 250200162 | Flat Washer M6.6 X 22 | 2 |
| 2 | 705003841 | Support Plate | 2 |
| 1 | 705012414 | Yellow, RH Hood Ass'y | 1 |
| 1 | 705011322 | Removable Hood | 1 |
| 4 | 517306478 | Clip | 4 |
| 1 | 705011323 | LH Front Mudguard | 1 |
| 8 | 250000712 | Torx Screw M6 X 20 | 8 |
| 6 | 233261494 | Hex. Elastic Flange Nut M6 | 6 |
| 4 | 250000721 | Torx Truss Screw M6 X 16 | 4 |
| 6 | 250000867 | Torx Truss Hex. Screw M6X35, Nylon Patch | 6 |
| 6 | 250000957 | Extruded Panel Nut M6 | 6 |
| 1 | 705011324 | RH Front Mudguard | 1 |
| 1 | 705011331 | LH Rocker Panel | 1 |
| 10 | 293150108 | Pop Rivet 3/16” | 10 |
| 4 | 250000867 | Torx Truss Hex. Screw M6X35, Nylon Patch | 4 |
| 2 | 250000840 | Torx Truss Screw Head PT.K50 X 40 | 2 |
| 1 | 705011332 | RH Rocker Panel | 1 |
| 1 | 705011335 | LH Rear Panel | 1 |
| 11 | 250000722 | Torx Screw M6 X 20 | 11 |
| 10 | 250200162 | Flat Washer M6.6 X 22 | 10 |
| 4 | 705003841 | Support Plate | 4 |
| 2 | 233161464 | Hex. Elastic Flange Nut M6 | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 1 | 705011336 | RH Rear Panel | 1 |
| 1 | 705011337 | Rear Box | 1 |
| 8 | 250100207 | Hex. Coupling Nut M6 | 8 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 | 4 |
| 5 | 250000745 | Hex Torx Truss M8 X30 | 5 |
| 5 | 234082670 | Stainless Steel Flat Washer | 5 |
| 3 | 250000807 | Torx Truss Screw M6 X 25 | 3 |
| 1 | 715005809 | Liquid Acces Cover | 1 |
| 1 | 705011426 | Rear Fascia | 1 |
| 1 | 704906815 | LH Rear Reflector | 1 |
| 1 | 704906816 | RH Rear Reflector | 1 |
| 3 | 250000957 | Extruded Panel Nut M6 | 3 |
| 4 | 250000807 | Torx Truss Screw M6 X 25 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 520001820 | Red Reflector | 2 |
| 1 | 705011512 | LH Rear Inner Fender | 1 |
| 3 | 293150104 | Pop Rivet 3/16" | 3 |
| 1 | 250000720 | Torx Screw K50 X 16 | 1 |
| 1 | 250200025 | Washer M5 | 1 |
| 1 | 705011513 | RH Rear Inner Fender | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 17 | 293150087 | Pop Rivet 3/16” | 17 |
| 17 | 224060251 | Washer | 17 |
| 1 | 705011325 | LH Front 60" Mud Guard Extension | 1 |
| 10 | 250000840 | Torx Truss Screw Head PT.K50 X 40 | 10 |
| 10 | 293150230 | Tuflok Plastic Rivet | 10 |
| 1 | 705011326 | RH Front 60" Mudguard Extension | 1 |
| 1 | 705012097 | LH Rear Mud Guard | 1 |
| 6 | 250000840 | Torx Truss Screw Head PT.K50 X 40 | 6 |
| 14 | 293150230 | Tuflok Plastic Rivet | 14 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 6 | 234062670 | Stainless Steel Flat Washer | 6 |
| 1 | 705012098 | RH Rear 60" Mud Guard Extension | 1 |
| 1 | 705012762 | LH Front Fender Extender | 1 |
| 18 | 293150230 | Tuflok Plastic Rivet | 18 |
| 1 | 705012763 | RH Front Fender Extender | 1 |
| 1 | 705012764 | LH Rear Fender Extender | 1 |
| 1 | 705012765 | RH Rear Fender Extender | 1 |
| 1 | 705207027 | LH Stricker Support | 1 |
| 4 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip | 4 |
| 1 | 705207028 | RH Stricker Support | 1 |
